77
UMG 96RM-M
100 SHORT RD/WR - Address of the measured value,
Digital output 1 0..32000 874
101 SHORT RD/WR - Address of the measured value,
Digital output 2 0..32000 882
102 FLOAT RD/WR Wh Pulse value,
Digital output 1 -1000000..+1000000 1000
104 FLOAT RD/WR Wh Pulse value,
Digital output 2 -1000000..+1000000 1000
106 SHORT RD/WR 10ms Minimum pulse length (1=10 ms)
Digital output 1/2 1..1000 5 (=50ms)
107 SHORT RD/WR - Result from comparator group 1; 0,1 0
Link A, B, C
(1=and, 0=or)
108 FLOAT RD/WR - Comparator 1A, Limit value -10
12
-1..+10
12
-1 0
110 SHORT RD/WR - Comparator 1A,
Address of the measured value 0..32000 0
111 SHORT RD/WR s Comparator 1A,
Minimum turn-on time 0..32000 0
112 SHORT RD/WR s Comparator 1A, Lead time 0..32000 0
113 SHORT RD/WR - Comparator 1A, Operator 0,1 0
„>=“=0, „<“=1
114 FLOAT RD/WR - Comparator 1B, Limit value -10
12
-1..+10
12
-1 0
116 SHORT RD/WR - Comparator 1B,,
Address of the measured value 0..32000 0
117 SHORT RD/WR s Comparator 1B,
Minimum turn-on time 0..32000 0
118 SHORT RD/WR s Comparator 1B, Lead time 0..32000 0
119 SHORT RD/WR - Comparator 1B, Operator 0,1 0
„>=“=0 „<“=1
120 FLOAT RD/WR - Comparator 1C, Limit value -10
12
-1..+10
12
-1 0
Address Format RD/WR Unit Note Adjustment Range Default
Parameter list comparator and digital outputs
