janitza UMG 96 RM-M User Manual

61
UMG 96RM-M
Telegramm
Data
point
Discription DIF DIFE DIFE DIFE VIF VIFE
1 Real energy,
without backstop dev.
0x06 X X X 0x04 X
2 Real energy, obtained 0x86 0x10 X X 0x04 X
3 Real energy, supplied 0x86 0x20 X X 0x04 X
4 Reactive energy, inductive 0x86 0x40 X X 0x04 X
5 Reactive energy, capacitive 0x86 0x50 X X 0x04 X
6 Reac. energy,
without backst. dev
0x86 0x60 X X 0x04 X
7 Apparent energy 0x86 0x80 0x40 X 0x04 X
8 Runtime comparator 1a 0x84 0x40 X X 0x24 X
9 Runtime comparator 1b 0x84 0x80 0x40 X 0x24 X
10 Runtime comparator 1c 0x84 0xC0 0x40 X 0x24 X
11 Runtime comparator 2a 0x84 0x80 0x80 0x40 0x24 X
12 Runtime comparator 2b 0x84 0xC0 0x80 0x40 0x24 X
13 Runtime comparator 2c 0x84 0x80 0xC0 0x40 0x24 X
14 Operating hours counter 0x04 X X X 0x24 X
15 I_sum 0x84 0x80 0x80 0x40 0xFD 0x59
16 P_sum 0x84 0xC0 0x80 0x40 0x2B X
17 Q_sum
mains frequency
0x84 0x80 0xC0 0x40 0x2B X
18 S_sum 0x84 0xC0 0xC0 0x40 0x2B X
