janitza UMG 96 RM-M User Manual

101
UMG 96RM-M
904 FLOAT RD var Harmonic distortion power D3 L3N
906 FLOAT RD var Sum; Dsum3=D1+D2+D3
908 FLOAT RD % THD1 I1, based on I01
910 FLOAT RD % THD2 I2, based on I02
912 FLOAT RD % THD3 I3, based on I03
914 FLOAT RD % TDD1 I1, based on rated load current
916 FLOAT RD % TDD2 I2, based on rated load current
918 FLOAT RD % TDD3 I3, based on rated load current
920 FLOAT RD - Current, zero sequence
922 FLOAT RD - Current, negative sequence
924 FLOAT RD - Current, positive sequence
926 FLOAT RD A Current, real part I L1
928 FLOAT RD A Current, real part I L2
930 FLOAT RD A Current, real part I L3
932 FLOAT RD A Current, imaginary part I L1
934 FLOAT RD A Current, imaginary part I L2
936 FLOAT RD A Current, imaginary part I L3
938 FLOAT RD - Rotation field; 1=right, 0=none, -1=left
Addresse Format RD/WR Unit Note
Type Size Minimum Maximum
short 16 bit -2
15
2
15
-1
ushort 16 bit 0 2
16
-1
int 32 bit -2
31
2
31
-1
uint 32 bit 0 2
32
-1
float 32 bit IEEE 754 IEEE 754
Number formats
C
Notes on saving measurement values and con-
figuration data:
• The following measurement values are saved at
least every 5 minutes:
• Comparator timer
• S0 meter readings
• Minimum / maximum / mean values
• Energy values
• Configuration data is saved immediately!
