Connection options
Connection of a UMG 96RM-M to a PC via a M-Bus
signal converter (RS232):
Netzanalysesoftware GridVis
The UMG 96RM-M can be programmed and read with
the GridVis network analysis software (Download: www.
janitza.com). For this a PC must be connected via a serial
interface (RS232 / USB) for example via an M-Bus Mas-
ter (level converter) to the M-Bus interface of the UMG
96RM-M.
The configuration of the UMG96RM-M is implemented
exclusively via the two buttons on the device - the Grid-
Vis software does not support this function!
It is not possible to read out M-Bus devices provided by
other manufacturers using the GridVis software!
Characteristics of GridVis
• Reading of online measurement values
• Graphical representation of measured values
PC
GridVis
Signal
converter
UMG 96RM-M
UMG 96RM-M
USB M-Bus
M-Bus
Connection of a UMG 96RM-M to a PC via a M-Bus
signal converter (USB):
PC
GridVis
Signal
converter
UMG 96RM-M
UMG 96RM-M
RS232 M-Bus
M-Bus
Item-No. 15.06.048
