103
UMG 96RM
Connection example
1)
UL/IEC approved overcurrent
protection device (6 A, type C)
2)
UL/IEC approved overcurrent
protection device (10 A, type C)
3)
Jumpers (external)
13 14 15
~
16 17
B
A
Digital outputs
RS485
Basic device
UMG 96RM
L1
L2
L3
N
V1 V2 V3 VN
Voltage input
3 4 5 6
I1 I2 I3
Current input
7 8 9 10 11 12
Supply
voltage
N L
1 2
A B
24V
DC
K1 K2
Consumer
230V/400V 50Hz
3) 3) 3)
2)1) 2) 2)
