14
UMG 96RM
Installation
Supply voltage
A supply voltage is required to operate the UMG 96RM.
The voltage supply is connected via plug-in terminals
on the back of the device.
Before applying the supply voltage, ensure that
the voltage and frequency correspond with the details
on the nameplate!
The supply voltage must be connected via a UL/IEC
approved fuse (6 A, type C).
Fig. Connection example of the supply voltage
to the UMG 96RM
Separator
Fuse
N
L
