UMG 96RM
Measured value relay
All measured values are calculated every nine periods
and can be recalled once per second on the measured
value displays. Two methods are available for retrieving
the measured value displays:
• The automatically changing display of selected
measured values, referred to here as measured value
relaying.
• Selection of a measured value display using buttons
1 and 2 from a preselected display profile.
Both methods are simultaneously available. Measured
value relaying is active if at least one measured value
display is programmed with a changeover time greater
than 0 seconds.
If a button is pressed, the measured value displays
of the selected display profile can be browsed. If no
button is pressed for about 60 seconds, the device
switches to the measured value relay and the measured
values from the selected display change profile
of the programmed measured value displays are shown
one after the other.
Changeover time (addr. 039)
Adjustment range: 0 .. 60 seconds
If 0 seconds are set, no changeover takes place between
the measured value displays selected for the measured
value relay.
The changeover time applies for all display change
profiles.
Display change profile (addr. 038)
Adjustment range: 0 .. 3
0 - Display changeover profile 1, by default.
1 - Display changeover profile 2, by default.
2 - Display changeover profile 3, by default.
3 - Customised display changeover profile.
Measured value displays
After return of the power supply, the UMG 96RM shows
the first measured value panel from the current display
profile. In order to keep the selection of measured values
to be displayed arranged in a clear manner, only one part
of the available measured values is pre-programmed
for recall in the measured value display by default. A dif-
ferent display profile can be selected if other measured
values are required to be shown on the UMG 96RM dis-
play.
