79
UMG 96RM
Supply voltage
Installation overvoltage category 300V CAT II
Protection of the power supply (fuse) 6 A, type C (approved by UL/IEC)
Nominal range 95V - 240V (45..65Hz) or DC 100V - 300V
Working area +-10% from the nominal range
Power consumption max. 8.5VA / 3.5W
Connection capacity of the terminals (power supply)
Connectable conductor. Only one conductor may be connected per contact point!
Single-wire, multi-wire, finely stranded conductor 0.2 - 2.5 mm
2
, AWG 24 - 12
Pin terminals, ferrules 0.25 - 2.5 mm
2
Tightening torque 0.5 - 0.6 Nm
Stripping length 7 mm
Outputs
2 digital outputs, semi-conductor relay, not short circuit protected.
Switching voltage max. 33 V AC, 60 V DC
Switching current max. 50 mAeff AC/DC
Reaction time 9 periods + 10 ms *
Pulse output (energy pulses) max. 50 Hz
* Reaction time at 50 Hz, for example: 180 ms + 10 ms = 190 ms
