85
UMG 96RM
20 FLOAT RD/WR A Current transformer I2, sec. 1..5 5
22 FLOAT RD/WR V Voltage transformer V2, prim. 0..1000000 400
24 FLOAT RD/WR V Voltage transformer V2, sec. 100, 400 400
26 FLOAT RD/WR A Current transformer I3, primary 0..1000000 5
28 FLOAT RD/WR A Current transformer I3, sec. 1..5 5
30 FLOAT RD/WR V Voltage transformer V3, prim. 0..1000000 400
32 FLOAT RD/WR V Voltage transformer V3, sec. 100, 400 400
34 SHORT RD/WR Hz Frequency determination 0, 45 .. 65 0
0=Auto, 45 .. 65=Hz
35 SHORT RD/WR - Display contrast 0 .. 9 5
0 (low), 9 (high)
36 SHORT RD/WR - Backlight 0 .. 9 6
0 (dark), 9 (light)
37 SHORT RD/WR - Display profile 0 .. 3 0
0=default display profile
1=default display profile
2=default display profile
3=freely selectable display profile
38 SHORT RD/WR - Display change profile 0 .. 3 0
0..2=default display
change profiles
3=freely selectable
display change profile
39 SHORT RD/WR s Changeover time 0 .. 60 0
40 SHORT RD/WR - Averaging time, I 0 .. 8* 6
41 SHORT RD/WR - Averaging time, P 0 .. 8* 6
42 SHORT RD/WR - Averaging time, U 0 .. 8* 6
50 SHORT RD/WR - Password 0 .. 999 0 (no password)
Address Format RD/WR Unit Note Adjustment Range Default
* 0 = 5sec.; 1 = 10sec.; 2 = 15sec.; 3 = 30sec.; 4 = 1min.; 5 = 5min.; 6 = 8min.; 7 = 10min.; 8 = 15min.
