Page #15 background imageLoading...
Page #15 background image
www.janitza.com UMG 96-S2
15
3.13 Overview of range of functions
3.13.1 Configuration on the device
(via 2 keys)
· Password protection (exclusively configurable
on the device)
· Primary / secondary current transformer (1...5
selectable)
· Primary / secondary voltage transformer
· Parameter and Modbus addresses, e.g.:
- Baud rate (RS485 interface)
- Data frame (stop bits / parity)
- Pulse value
- Pulse pause
- Pulse output: Active, apparent or reactive
energy
- LCD contrast
3.13.2 Communication
· Modbus RTU protocol (RS485 interface).
· Firmware update via RS485 interface.
3.13.3 Digital output
· 1 digital output (S0 interface) for outputting
the active energy, reactive energy or apparent
energy obtained.
Specify the pulse capability and pulse pause for
configuration.
3.13.4 Measured values
Value
Phase
1..3
Total Current Maxi-
mum
Mini-
mum
Aver-
age
Maximum
of the
average
(max. mean
value)
Voltages L-N
ü ü ü ü ü
Outer conductor voltages L-L
ü ü ü ü ü
Current
ü
calculates
N current
ü ü ü ü
Active power
ü ü ü ü ü ü
Reactive power
ü ü ü ü ü
Active power (mains frequency)
ü ü ü ü ü ü
Apparent power
ü ü ü ü ü ü
Frequency
ü ü ü ü ü
Rotation field
ü
Phase angle
ü ü
Power factor
ü ü ü
THD U (harmonics content)
ü ü ü ü ü
THD I (harmonics content)
ü ü ü ü ü
Harmonic U 1..15 (odd)
ü ü ü
Harmonic I 1..15 (odd)
ü ü ü
Active energy (obtained)
ü ü ü
Active energy (supplied)
ü ü ü
Reactive energy (inductive)
ü ü ü
Reactive energy (capacitive)
ü ü ü
Apparent energy
ü ü ü
Operating hours counter
ü
Rates
ü
Tab. Overview of the measured values that are recorded by the device.
More information on the measured values can be found in chap.„18.1 Function characteristics“ on page 60.
