UMG 96-S2 www.janitza.com
52
15. Connection example
=
+
-
Spannungsmessung
Voltage measurement
Strommessung
Current measurement
V1 V2 V3 VN
3 4 5 6
1 2
N/- L/+
S2
S1
S2
S2
S1
S1
L1
L2
L3
Verbraucher
Consumer
230V/400V 50Hz
N
S2 S1 S2 S1 S2 S1
UMG 96-S2
13
CA
RS485
Digitaler Ausgang
Digital output
Versorgungsspannung
Power supply voltage
RS485-Bus
Data GND
Funktionserde
Functional ground
A
C
C
BV+
B
A
B
14151617
2) 2) 2)
1)
1)
1) 1)
1) UL/IEC approved fuse protection
2) Jumpers (external)
Fig. Connection example for UMG 96-S2
