UMG 96-S2 www.janitza.com
64
Modbus
address
Address via
display
Format RD/WR Unit Remark
19100 - float RD varh Reactive energy, inductive, L1..L3
19102 - float RD varh Reactive energy, capacitive, L1
19104 - float RD varh Reactive energy, capacitive, L2
19106 - float RD varh Reactive energy, capacitive, L3
19108 - float RD varh Reactive energy, capacitive, L1..L3
19110 836 float RD % Harmonic, THD, U L1-N
19112 838 float RD % Harmonic, THD, U L2-N
19114 840 float RD % Harmonic, THD, U L3-N
19116 908 float RD % Harmonic, THD, l L1
19118 910 float RD % Harmonic, THD, l L2
19120 912 float RD % Harmonic, THD, l L3
18.5 Number formats
Type Size Minimum Maximum
short 16 bit -2
15
2
15
-1
ushort 16 bit 0 2
16
-1
int 32 bit -2
31
2
31
-1
uint 32 bit 0 2
32
-1
float 32 bit IEEE 754 IEEE 754
18.6 Note on saving measured values
and configuration data
NOTE
Note on saving measured values
and configuration data:
• Since the following measured values are
saved in a non-volatile memory every 5
minutes, the recording may be interrupted
for a maximum of 5 minutes in case the
operating voltage fails:
• Comparator timer
• S0 counter statuses
• Min. / Max. / mean values
(without the date and time)
• Energy values
• Configuration data is saved immediately.
A detailed Modbus address and parameter list
can be found at www.janitza.com
