4. Design of the device
4.1 Front view - display
Pos. Designation Description
1 Manufacturer logo Logo of the device manufacturer
2 QR code Coded figure of the device web site from the manufacturer
3 Device display See chap. „11. Operation and button functions“ on page 33
4 Device type
5 Key 1 See chap. „11. Operation and button functions“ on page 33
6 Key 2 See chap. „11. Operation and button functions“ on page 33
7 Device designation
2
3
4
6
5
7
Fig. Front view of UMG 96-S2
1
