Table of Contents

Table of Contents4
General Information8
- Disclaimer8
- Copyright Notice8
- Technical Changes8
- About this User Manual8
- Defective Device/Disposal8
Safety10
- Presentation of Warning Notices and Safety Instructions10
- Danger Levels10
- Product Safety10
- Dangers When Handling the Device10
- Electrically Qualified Personnel11
- Warranty in the Event of Damage11
Product Description12
- Device Description12
- Incoming Goods Inspection12
- Intended Use12
- Device Characteristics12
- Device Functions12
- Performance Features13
- EC Declaration of Conformity14
- Scope of Delivery14
- Available Accessories14
- Measurement Method14
- Operating Concept14
- Gridvis Network Analysis Software14
- Overview of Range of Functions15
Design of the Device16
- Front View - Display16
- Rear View - Location of the Connections17
- Labeling of the Device - Rating Plate18
Assembly20
- Installation Location20
- Installation Position20
- Fastening20
Network Systems21
Installation21
- Rated Voltages21
  - Three-Phase 4-Conductor Network with Grounded Neutral Conductor21
- Disconnectors22
- Supply Voltage22
- Voltage Measurement23
- Current Measurement24
Connection27
- Connection to a PC27
- RS485 Interface (Serial Interface)27
- Shielding28
- Termination Resistors28
- Bus Structure29
Communication Via the RS485 Interface with the Modbus RTU Protocol30
Digital Output31
- Pulse Output Function31
- Pulse Output Connection Example31
- Pulse Value (Parameter Address 102)31
- Pulse Length (Parameter Address 106) and Pulse Pause32
- Determining the Pulse Value32
Operation and Button Functions33
- Operation33
- Button Functions34
- Parameter (Addresses) and Measured Value Display35
Configuration36
- Connecting the Supply Voltage36
- Programming Mode36
- Password Protection36
- Current Transformer and Voltage Transformer36
- Programming the Current Transformer37
- Programming the Voltage Transformer37
- Programming the Parameters38
- Important Information for Configuration40
Commissioning42
- Connecting the Supply Voltage42
- Connecting the Measured Voltage42
- Connecting the Measured Current42
- Checking the Phase Sequence42
- Checking the Phase Assignment42
- Checking the Power Measurement42
- Checking the Measurement42
- Checking the Individual Powers43
- Checking the Sum Powers43
Measured Value Display and Automatic Display Change Profile44
- Measured Value Displays44
- Automatic Display Change Profile44
- Programming Measured Value Displays Via the Gridvis44
  - Software44
- Overview of Measured Value Displays - Display Profile46
- Overview of Automatic Display Change Profiles50
Connection Example52
Service and Maintenance54
- Repair and Calibration54
- Front Film and Display54
- Device Adjustment54
- Firmware Update54
- Service54
Error Messages55
- Warnings55
- Serious Errors55
- Internal Error Cause Recognition55
- Exceeding the Measurement Range56
- Measurement Range Exceedance Parameter56
- Procedure in the Event of Errors57
Technical Data58
- Function Characteristics60
- Parameter and Modbus Address List62
- Table 2 - Modbus Address List (Excerpt of the Frequently Required Measured Values)63
- Number Formats64
- Note on Saving Measured Values and Configuration Data64
Dimensional Drawings65
