Supply voltage
Installation overvoltage category 300V CAT II
Protection of the power supply (fuse) 6 A, type C (approved by UL/IEC)
Nominal range 20V - 250V (45..65Hz) or DC 20V - 300V
Working area +-10% from the nominal range
Power consumption max. 13VA / 3W
Connection capacity of the terminals (power supply)
Connectable conductor. Only one conductor may be connected per contact point!
Single-wire, multi-wire, finely stranded conductor 0.2 - 2.5mm
2
, AWG 26 - 12
Pin terminals, ferrules 0.2 - 2.5mm
2
Tightening torque 0.4 - 0.5Nm
Stripping length 7mm
Digital outputs
6 digital outputs, semi-conductor relay, not short circuit protected.
Switching voltage max. 33V AC, 60V DC
Switching current max. 50mAeff AC/DC
Reaction time 10/12 Perioden + 10ms *
Pulse output (energy pulses) max. 50Hz
* Reaction time at 50 Hz, for example: 200 ms + 10 ms = 210 ms
