UMG 96RM-P/-CBM
Profibus profile number 9
Byte
index
Value type Value
format
Scaling
1 1 Effective energy sum L1..L3 Float 1
2 5 Effective energy sum L1..L3 drawn Float 1
3 9 Effective energy sum L1..L3 delivered Float 1
4 13 Reactive energy sum L1..L3 Float 1
5 17 Ind. reactive energy sum L1..L3 Float 1
6 21 Cap. reactive energy sum L1..L3 Float 1
7 25 Apparent energy sum L1..L3 Float 1
8 29 Effective energy L1 Float 1
9 33 Effective energy L2 Float 1
10 37 Effective energy L3 Float 1
11 41 Inductive reactive energy L1 Float 1
12 45 Inductive reactive energy L2 Float 1
13 49 Inductive reactive energy L3 Float 1
Profibus profile number 8
Byte
index
Value type Value
format
Scaling
1 1 Effective voltage L1 Float 1
2 5 Effective voltage L2 Float 1
3 9 Effective voltage L3 Float 1
4 13 Effective voltage L1-L2 Float 1
5 17 Effective voltage L2-L3 Float 1
6 21 Effective voltage L3-L1 Float 1
7 25 Effective current L1 Float 1
8 29 Effective current L2 Float 1
9 33 Effective current L3 Float 1
10 37 Effective current L4 Float 1
11 41 Effective current sum L1..L3 Float 1
12 45 Effective power L1 Float 1
13 49 Effective power L2 Float 1
14 53 Effective power L3 Float 1
15 57 Cos phi (math.) L1 Float 1
16 61 Cos phi (math.) L2 Float 1
17 65 Cos phi (math.) L3 Float 1
18 69 Frequency Float 1
19 73 Effective power sum L1..L3 Float 1
20 77 Reactive power fundamental oscillation
harmonic sum L1..L3
Float 1
21 81 THD voltage L1 Float 1
22 85 THD voltage L2 Float 1
23 89 THD voltage L3 Float 1
24 93 THD current L1 Float 1
25 97 THD current L2 Float 1
26 101 THD current L3 Float 1
27 105 THD current L4 Float 1
C
The configuration/programming is imple-
mented via the GridVis software included
in the scope of deliverables. A connection
between the UMG 96RM-P and the PC via
an interface is required for the use of the
GridVis software.
