60
Spare Tire Carrier (if so equipped)
If your recreational vehicle is equipped with a spare tire, it will either be mounted under the
unit (hoist) or on the rear bumper.
Depending on your model, the spare tire may have (side or bottom) brackets or it will be
mounted against the underside of the recreation vehicle (ush mount) to give it stability in
travel.
The crank handle to raise and lower the tire will be located (fastened to the sidewall) in a
basement compartment of the recreational vehicle. Insert the crank handle into the crank
access port located either in the center of the rear bumper, or on the sidewall of the RV. Turn
the crank handle to raise/lower the tire. Two “crisp breaks” must be heard and felt to insure
the proper seating of the tire for travel.
DO NOT exceed the maximum load capacities of 100 lbs. for the hoist. DO
NOT use air driven guns or impact wrenches to lift the spare tire to the travel
position.
If your spare tire is a ush mount application, it must make contact
with the underside of the recreational vehicle to insure maximum road clear-
ance and stability in travel. Raising and lowering the hoist
1. Keep the recreational vehicle attached to the tow vehicle. Block the tire on the opposite
side of the recreational vehicle from the tire you are changing.
2. Loosen the wheel lug on the tire you are changing before jacking up the vehicle. DO
NOT remove the lug nuts; only loosen them for ease of removal when the tire is o
the ground.
3. Locate the mainframe rail of the trailer (it spans from front-to-back just inside the tires).
4. To raise the recreational vehicle, place the jack (hydraulic or screw) under the main
frame rail. It must be just ahead of the front tire or just behind the rear tire.
Any service or warranty coverage on tires is to be handled by the tire manufacturer or the
store representing the brand installed on your recreation vehicle. They are not to be returned
to your dealer or recreation vehicle manufacturer.
