To secure the spare tire in the travel position, put the steel hoist lift
support located on the end of the cable through the rim of the tire. The hoist lift support clips
need to seat inside the center hole of the tire rim. The valve stem of the tire MUST be
pointed up (toward the bottom of the RV).
The spare tire bracket can be released and extended down
to access a storage compartment at the rear of the trailer
without removing the tire.
1. Remove the cotter key from the pin holding the tire
carrier in place.
2. Remove the pin and extend the carrier away from the
trailer.
1. Remove the lug nuts holding the tire in place.
2. Remove the support bracket from the bottom lug.
3. Pull the tire from the tire carrier.
1. Place the tire on the carrier with the top lug bolt in-
serted into one of the holes in the tire rim and the
bottom lug bolt in the center of the rim.
2. Install the top lug nut.
3. Place the support bracket over the bottom lug bolt
across the center of the rim (photo).
4. Install the bottom lug nut over the support bracket.
5. Tighten the lug nuts securely before returning to travel.
If the manual crank access port is
located in a slideout, the slideout room must be in
the travel position to allow the crank to reach the
mechanism used to raise or lower the tire.
