jcb 1CX User Manual

3 - 1
Section 1 General Information
9803/8550
Section 1
3 - 1
Issue 8
Service Tools
Numerical List
Page No.
1406/0011 Bonded Washer 4 - 3
1406/0018 Bonded Washer 4 - 3
1406/0021 Bonded Washer 4 - 2/4 - 3
1406/0029 Bonded Washer 4 - 3
1604/0003 Adapter 4 - 3
1604/0004 Adapter 4 - 3
1604/0006 Adapter 4 - 2/4 - 3
1606/0003 Adapter 4 - 3
1606/0004 Adapter 4 - 3
1606/0007 Adapter 4 - 3
1606/0008 Adapter 4 - 3
1606/0009 Adapter 4 - 3
1612/0006 Adapter 4 - 2
4101/0251 Threadlocker and Sealer 5 - 1
4101/0451 Threadlocker 5 - 1
4101/0552 Threadlocker & Sealer (High Strength) 5 - 1
4101/0651 Retainer (High Strength) 5 - 1
4102/0551 High Strength Threadlocker 5 - 1
4102/1201 Multi-Gasket 5 - 1
4104/0251 Activator (Aerosol) 5 - 1
4104/0253 Activator (Bottle) 5 - 1
4104/1557 Cleaner/Degreaser 5 - 1
816/00189 Blanking Cap 4 - 4
816/00190 Blanking Cap 4 - 4
816/00193 Blanking Cap 4 - 4
816/00196 Blanking Cap 4 - 4
816/00197 Blanking Cap 4 - 4
816/00294 Blanking Cap 4 - 4
816/15118 Pressure Test Adapter 4 - 2
816/20008 Adapter 4 - 2
816/50043 'T' Adapter 4 - 4
816/55038 Pressure Test 'T' Adapter 4 - 2
816/55040 Pressure Test 'T' Adapter 4 - 2
816/60096 'T' Adapter 4 - 4
892/00047 'T' Adapter 4 - 4
892/00048 'T' Adapter 4 - 4
892/00055 Blanking Plug 4 - 4
892/00056 Blanking Plug 4 - 4
892/00057 Blanking Plug 4 - 4
892/00059 Blanking Plug 4 - 4
892/00060 Blanking Plug 4 - 4
892/00074 Female Connector 4 - 4
892/00075 Female Connector 4 - 4
892/00077 Female Connector 4 - 4
892/00137 Hose 4 - 3
892/00223 Hand Pump 4 - 3
892/00252 Test Block 4 - 3
892/00253 Pressure Test Kit 4 - 2
892/00255 Pressure Test Adapter 4 - 2
892/00256 Pressure Test Adapter 4 - 2
892/00257 Pressure Test Adapter 4 - 2
892/00258 Pressure Test Adapter 4 - 2
892/00259 Pressure Test Adapter 4 - 2
892/00260 Pressure Test Adapter 4 - 2
892/00261 Pressure Test Adapter 4 - 2
892/00262 Pressure Test 'T' Adapter 4 - 2/4 - 3
892/00263 Pressure Test 'T' Adapter 4 - 2
892/00264 Pressure Test 'T' Adapter 4 - 2
892/00265 Pressure Test 'T' Adapter 4 - 2
Page No.
892/00268 Flow Monitoring Unit 4 - 2
892/00269 Sensor Head 4 - 2
892/00270 Load Valve 4 - 2
892/00271 Adapter 4 - 2
892/00272 Adapter 4 - 2
892/00274 Adapter 4 - 3
892/00275 Adapter 4 - 2
892/00276 Adapter 4 - 2
892/00277 Adapter 4 - 2
892/00278 Gauge 4 - 3
892/00279 Gauge 4 - 3
892/00281 AVO Meter 4 - 1
892/00282 Shunt 4 - 1
892/00283 Tool Kit Case 4 - 1
892/00284 Tachometer 4 - 1
892/00285 Hydraulic Oil Temperature Probe 4 - 1
892/00286 Surface Temperature Probe 4 - 1
892/00706 Test Probe 4 - 3
892/00858 Pump Support Bracket 4 - 4
892/01017 Ram Seal Protection Sleeve 4 - 5
892/01018 Ram Seal Protection Sleeve 4 - 5
892/01027 Piston Seal Assembly Tool 4 - 5
992/09300 Spanner 4 - 3
992/09400 Spanner 4 - 3
992/09500 Spanner 4 - 3
992/09600 Spanner 4 - 3
993/99510 Half Moon Spanner 4 - 4
The following parts are replacement items for kits and would
normally be included in the kit numbers quoted above.
Replacement items for kit no. 892/00253
892/00201 Replacement Gauge 4 - 2
892/00202 Replacement Gauge 4 - 2
892/00203 Replacement Gauge 4 - 2
892/00254 Replacement Hose 4 - 2
