Section C Electrics
9803/8550
Section C
Issue 5*
1 - 1
System Type
Battery
Cold crank amps for 1 minute to
1.4 VPC at -18 °C (0 °F)
Reserve capacity (minutes) for 25 Amp load
Alternator
XUD Engines
100 and 400 Series Engines
Light Bulbs
Working Lights
Indicator Lights
Warning Lights
Beacon (if fitted)
Interior Light (if fitted)
Side Lights (if fitted)
Relays up to machine no. 751599
Overheat Delay Relay A
Alarm Buzzer B
Indicator Flasher Relay C
Neutral Start Relay D
Loader Isolation Relay E
Horn Relay F
Glow Plug Relay G
12 Volts, negative earth
420 to 585
170 to 230
12V, 50 Amp output
12V, 55 Amp output
55W (Halogen)
21W
1.2W
70W
10W
5W
1 - 1
Technical Data
according to battery type
A
B
C
F
G
S202800
S203822
D
E
*
