1 - 1
Section K Engine
9803/8550
Section K
1 - 1
Technical Data - XUD engine
Type
Bore (nominal)
Stroke
Swept Volume
Compression Ratio
Compression Pressure (Measured with warm engine
turned by the starter)
Injection Sequence
Valve Clearance - Cold - Inlet
Exhaust
Maximum Air Cleaner Restriction
Maximum Back Pressure (Exhaust)
Speeds
Maximum Loaded
Maximum No Load - standard machines
Maximum No Load - High-flow machines
Idling Speed
Oil Pressure at 110 °C (230 °F) at loaded speed
Fuel System
Injection Pump Type
Governing
Pump Setting Code
Static Timing
Injector Codes
Injector Setting Pressure
Cooling System
Fan Type
Coolant Pressure
Temperature Warning Light operates at
4 cylinder in-line, overhead camshaft, compression ignition, naturally
aspirated.
83 mm (3.268 in)
88 mm (3.465 in)
1905 cm
3
(116.24 in
3
)
23.5 : 1
25 - 30 bar (363 - 435 lbf/in
2
, 25.5 - 33 kgf/cm
2
)
Maximum variation between cylinders 5 bar (72.5 lbf/in
2
, 5.1 kgf/cm
2
)
1,3,4,2
0.15 - 0.20 mm (0.0059 - 0.0078 in)
0.30 - 0.35 mm (0.0118 - 0.0138 in)
20 mbar (0.29 lbf/in
2
, 0.02 kgf/cm
2
) at 3600 rev/min
140 mbar (2.03 lbf/in
2
, 0.143 kgf/cm
2
) at 3600 rev/min
2630 rev/min
3000 rev/min
3500 rev/min
880 - 920 rev/min
3.6 bar (52.2 lbf/in
2
, 3.7 kgf/cm
2
)
Lucas CAV DPC R84 43
Mechanical
063
16
+
/-
1° BTDC
RDN O5DC 6730
115
+
/- 5 bar (1667.5
+
/- 72.5 lbf/in
2
, 117
+
/- 5.1 kgf/cm
2
)
Mechanical
1 bar (14.5 lbf/in
2
, 1.02 kgf/cm
2
)
105
+
/-
2 °C (221
+
/-
3.6 °F)
Issue 4*
Specification
Note: If at anytime during the life of a machine it is necessary to fit a new engine, then after the first 50 operating hours a new
engine oil filter must be fitted and the engine oil changed. Failure to complete this could damage the engine.
Note: Should further details be required for the refitting of the engine refer to Engine Service Manual 9803/8600.
*
