jcb 1CX User Manual

2 - 2
Section 1 General Information
9803/8550
Section 1
2 - 2
Issue 1
Torque Settings
BSP Adapters with Bonded Washers.
Adapter Size Spanner size Torque Settings
in mm Nm kgf m lbf ft
1
/8 11 20 2.0 15
1
/4 19 34 3.5 25
3
/8 22 75 7.6 55
1
/2
27 102 10.4 75
5
/
8 30 122 12.4 90
3
/4 32 183 18.7 135
1 38 203 20.7 150
1
1
/
4 305 31.1 225
1
1
/2 305 31.1 225
SAE Adapters with ‘O’ rings.
Adapter Size Torque Settings
in Nm kgf m lbf ft
7
/16 20 2.0 15
9
/16 35 3.6 26
3
/4 81 8.3 60
7
/8 108 11.0 80
1
1
/16
183 18.7 135
1
5
/16 298 30.4 220
1
5
/
8 380 38.8 280
Hydraulic Coned BSP Hoses.
Hose Size Spanner size Torque Settings
in mm Nm kgf m lbf ft
1
/8 14 14 1.4 10
1
/
4 19 27 2.7 20
3
/8 22 40 4.0 29
1
/2 27 55 5.6 40
5
/8 30 65 6.6 48
3
/4 32 95 9.7 70
1 38 120 12.2 88
1
1
/4 189 19.3 139
1
1
/2 244 24.9 180
