jcb Dumpster HTD5 - Page 133

Section E - Hydraulics
Valves
Control Valve
E-36 E-36
9803-9570-4
Lift Section
Fig 9.
Torque Settings Nm Lbf ft
Cap Screws (A) 4 - 6 3.0 - 4.4
Load Hold Valve Plug (B)2014.8
Plug (C)6044
A
A
C
C
B
