IN CASE OF EMERGENCY
114
IGNITION KEY EMERGENCY
REMOVAL
The ignition key (for versions with a
mechanical key) can be removed only if
the gear lever is in position P ("Park").
If the car's battery is discharged, the
ignition key, if inserted, remains locked in
its seat.
Proceed as follows to extract the key fob
manually:
stop the car in safety conditions,
engage a gear and the electric parking
brake;
using the provided key (A) fig.89
(located in the casing containing the
handbook) undo the fixing screws (B)
fig.90 for the lower upholstery (C);
remove the lower steering column
upholstery (C) by releasing it from its
housing;
use one hand to pull down the tab (D)
fig.91 and use the other to remove
the key, sliding it outward;
once the key has been removed, refit
lower upholstery (C) fig.90, make
sure it locks correctly and tighten the
fixing screws (B) firmly.
A
89 J0B6132E
90 J0B6133E
91 J0B6134E
10)
