ENGINE COMPARTMENT
CHECKING LEVELS
66) 67) 68) 69) 70)
11)
92 J0B6037E
A.Engine oil dipstick - B.Engine oil filler cap - C.Heat engine coolant fluid - D.High voltage system coolant - E.Windscreen/rear window washer
fluid - F.Brake fluid - G.Low voltage battery (12V)
NOTE The cooling tank of the high voltage system cannot be refi lled by the driver. If it is necessary to top up the fl uids, contact a Jeep
Dealership.
