17
3 J0B6062
4 J0B6063
"MODE2" CHARGING CABLE
The car is equipped with a "Mode 2" 230
Volt AC (A)fi g.5 charging cable located
inside a special bag, fi g.6, placed in the
boot.
The cable consists of:
specific charge connector (B) for
connection to the vehicle;
a charge status control unit (C)
equipped with LEDs, able to provide
indications on any anomalies present
during the charging phase;
a connection plug (D) to a domestic
power socket.
NOTE After use, remember to correctly
replace the protective cover (where
provided) on the specifi c charging
connector (B) to prevent moisture and/or
dust from getting inside.
5 J0B6048E
6 J0B6059E
