53
DIGITAL FUEL LEVEL GAUGE
The digital gage on the display shows the
amount of fuel (A)fi g.40 inside the tank.
The indications next to the graphic scale
indicate the amount of fuel:
F (Full) = full tank
E (Empty) = empty tank.
40 J0B6021E
FUEL RESERVE DISPLAY
When the fuel reserve level is left inside
the tank, (A)fi g.41, the indicator
turns yellow and the indication of the fuel
quantity and the letter "E" are displayed
in red.
B
A
41 J0B6022E
When the tank is completely empty
(B)fi g.41, the indicator turns yellow
and the last graphic notch on the digital
indicator and the letter "E" are displayed
in red.
The instrument panel display shows
a message and an acoustic signal is
emitted.
WARNING If the reserve warning light
switches on, refuel at the earliest
opportunity.
WARNING Do not travel with the fuel tank
almost empty: possible gaps in fuel supply
could damage the catalytic converter.
