KNOWING THE INSTRUMENT PANEL AND MULTIMEDIA

INSTRUMENT PANEL FEATURES

RECONFIGURABLE MULTIFUNCTION DISPLAY

km/h

450

5299

READY

39 J0B6026E

A.Tachometer - B.Digital fuel level gage with fuel reserve warning light (the triangle on the right side of the symbol indicates the side of the

vehicle where the fuel filler neck is located) - C.Reconfigurable 7" multifunction display - D.Digital vehicle range indicator (this indicator is not

fixed but can be selected from several others in the instrument panel menu) - E.Power meter (expressed as percentage %)

WARNING The illumination of the instrument panel graphics may vary according to version.
