IN CASE OF EMERGENCY 365
5. Cycle the ignition to OFF.
6. Block both the front and rear of the wheel
d
iagonally opposite the jacking position. For
example, if the driver’s front wheel is being
changed, block the passenger’s rear wheel.
Wheel Blocked
NOTE:
Passengers should not remain in the vehicle
wh
en the vehicle is being jacked in position.
JACK LOCATION
The jack and tools are stored under the right
rear seat. To remove jack and tools proceed as
follows:
1. Fold up the right rear seat.
2
. Remove the jack and tools by turning the
w
ing bolt counterclockwise, remove the
wing bolt and then lift the assembly out
from under the seat.
Jack And Tools
3. Release the tool bag straps from the jack
a
nd remove tools from bag.
Jack And Tool Bag
4. R
emove tool kit and assemble tools.
J
ack And Tool Bag
7
