SERVICING AND MAINTENANCE 415
Cavity Cartridge Fuse Micro Fuse Description
F01 – – Spare*
F02 40 Amp Green – Starter
F03 – 5 Amp Tan Intelligent Battery Sensor (IBS)
F04 – 20 Amp Yellow Fuel Pump MTR/FPCM
F05 – 5 Amp Tan Security Gateway
F06 – – Spare*
F07 – – Spare*
F08 – 15 Amp Blue Trans Control Module TCM-8HP CYGNUS
F09 – – Spare*
F10 – 15 Amp Blue
Key Ignition Node (KIN)/Radio Frequency Hub (RF HUB)/
E
l
ectric Steering Column Lock (ESCL)
F11 – 10 Amp Red UCI Port (USB & AUX)
F12 – 25 Amp Clear HIFI Amplifier
F13 – – Spare*
F14 – – Spare*
F15 – 15 Amp Blue
Instrument Panel Cluster (IPC)/Switch Bank-Heavy Duty
El
ectrical Pkg (SWITCH BANK-HD ELEC)
F16 – – Spare*
F17 – – Spare*
F18 – 10 Amp Red Air Conditioning Clutch (AC CLUTCH)
F19 – – Spare*
8
