SERVICING AND MAINTENANCE 417
F34 – 10 Amp Red
Electronic Stability Control (ESC)/Electric Hydraulic Power
St
eering (EHPS)/Smart Bar Control Module (SBCM) WAKE
UP
F35 30 Amp Pink – BRAKE VAC PMP*
F36 30 Amp Pink – TRAILER TOW MOD*
F37 30 Amp Pink – TRAILER TOW CONN 7W*
F38 20 Amp Blue – Engine Control Module (ECM)
F39 – – Spare*
F40 – 15 Amp Blue
Drivetrain Control Module (DTCM)/Axle Lock (AXLE LOC)
F
T
_RR
F41 – 15 Amp Blue Instrument Cluster (IC)/Security GateWay (SGW) WAKE UP
F42 – 10 Amp Red Power Control Relay Control Feed (Electric Stop/Start)
F43 – – Spare*
F44 – 10 Amp Red Infrared Camera (IRCAM) HEATERS
F45 – – Spare*
F46 – 10 Amp Red AUTO HDLP LVL MOD/LVL MTR/HDLP SW
F47 – – Spare*
F48 – – Spare*
F49 – 10 Amp Red Occupant Restraint Controller (ORC)
F50 – 10 Amp Red HD ACC*
Cavity Cartridge Fuse Micro Fuse Description
8
