Release Select Menu only after the three LED’s display the following blink
sequence:
LED Blink Sequence
Standby/Man.
Yellow ~ { { ~ { {
Pump running
Red { Ö ~ Ö { Ö { Ö ~ Ö {
OK
Green { { ~ { { ~ ....
The GSU display will simultaneously read:
Release key to:
- learn RC -
4. This procedure enables a system mode, whereby the control positions can be
learned by the ECU. When Select Menu is released, only the green OK LED should
illuminate.
The GSU display will read:
Æ “Off” position
Set Throttle
control channel
to minimum:
5. Now the ECU can memorize the positions of the throttle control channel. First, place
the throttle control channel to low. Next, press Select Menu or the LED I/O board
switch, again. This will store the R/C system’s pulse width for immediate shutdown of
the turbine. The green OK LED will turn off and the red Pump running LED will
illuminate. This indicates that the shutdown data has been set correctly.
The GSU display will read:
Æ Throttle channel “Idle” position
Throttle Trim to
maximum:
6. Advance the throttle control channel to the center position. Press Select Menu or
the LED I/O board switch again, to store the R/C system’s pulse width for the turbine
idle position. The red Pump running LED will turn off and the yellow Standby LED
will illuminate. This indicates that the turbine idle data has been set correctly.
The GSU display will read:
Æ Throttle channel “Full Power” position
Set Throttle to
maximum:
