SECTION 2 - PROCEDURES
3121801 2-35
2.20 FLASH CODES AND DESCRIPTIONS
Table 2-10. Help Messages and Flash Codes - Software P1.X
FLASH CODE HELP MESSAGES AND FLASH CODES
No Flash Code EVERYTHING OK
GROUND MODE OK
ALARM SOUNDING - TILTED & ABOVE ELEVATION
Platform is elevated and the chassis is not level.
DIFFERENT FUNCTION SELECTED & IGNORED
A function (i.e. Drive, Lift, etc.) is active and the operator has selected another function. The system has ignored the new selection.
DRIVING AT CUTBACK - ABOVE ELEVATION
Platform is elevated and the machine is in the drive mode of operation.
FUNCTION SELECTED BUT TRIGGER SWITCH OPEN
A function (i.e. Drive, Lift, etc.) has been selected by the operator, but the trigger switch is not active (closed).
JOYSTICK MOVED BUT NO FUNCTION SELECTED
The joystick was moved out of the center position before a function was selected.
DRIVE PREVENTED - ABOVE DRIVE CUTOUT HEIGHT
Machin is elevated above the drive cutout height.
2-1 STARTUP
A new system power up has occurred since the last help message.
2-2 FUNCTIONS LOCKED OUT - SHORT TO PLATFORM ROW INPUT DETECTED
Battery power has been detected on a row input (pins J1-8, J1-9, or J1-13).
FUNCTION PROBLEM - DRIVE PERMANENTLY SELECTED
Dr iv e se le ct swi tc h in th e pl atf or m co ntr ol b ox c lo sed at s ta r t up or for mo re th an ten sec on ds. Rel ea se s wi tch to c le ar f au lt.
FUNCTION PROBLEM - LIFT PERMANENTLY SELECTED
Li ft se lec t s wi tch in the pl atf or m co ntro l b ox cl os ed a t s tar t up o r f or m ore th an t en sec ond s. R el ea se s wi tch to c le ar f au lt
FUNCTION PROBLEM - O/R or L/J PERMANENTLY SELECTED
An outrigger select switch in the platform control box closed at start up or for more than ten seconds. Release switch to clear fault
FUNCTION PROBLEM - START PERMANENTLY SELECTED
Start switch in the platform control box closed at start up. Release switch to clear fault
FUNCTION PROBLEM - GLOW PLUG PERMANENTLY SELECTED
Glow plug switch in the platform control box closed at start up. Release switch to clear fault
FUNCTION PROBLEM - STEER LEFT PERMANENTLY SELECTED
Steer left switch in the platform control box closed at start up. Release switch to clear fault
FUNCTION PROBLEM - STEER RIGHT PERMANENTLY SELECTED
Steer right switch in the platform control box closed at start up. Release switch to clear fault
FUNCTION PROBLEM - HORN PERMANENTLY SELECTED
Ho rn swi tch in pla tfo rm con tro l bo x cl os ed at start up. Release switch to clear fault.
FUNCTION PROBLEM - JOYSTICK CALIBRATIONFAULTY
The Personalities for theJoystick are improperly adjusted or a joystick calibration attempt failed. Re-adjust or recalibrate.
JOYSTICK FAULTY - WIPER OUT OF RANGE
The joystick wiper signal input is outside the acceptable voltage range. The wiper wire being off, the wiper wire shorted to battery power, or the wiper wire
shorted to battery negative could cause this.
JOYSTICK FAULTY - STEER SWITCHES ACTIVE TOGETHER
Both the steer left and steer right inputs are closed at the same time. A short in the steer switch wiring or a failed steer switch can cause this.
FUNCTION LOCKED OUT - JOYSTICK NOT CENTERED
Selected function is not allowed because the joystick is not centered. Return joystick to center and reselect function.
FUNCTION PROBLEM - JOYSTICK CALIBRATION FAULTY
The Personalities for theJoystick are improperly adjusted or a joystick calibration attempt failed. Re-adjust or recalibrate
