SECTION 1 - SPECIFICATIONS
3121801 1-1
SECTION 1. SPECIFICATIONS
1.1 OPERATING SPECIFICATIONS 1.2 CAPACITIES
1.3 COMPONENT DATA
Engine
Table 1-1. Operating Specifications
Machine Weight 3701 kg (8160 lbs)
Machine Height:
Fully Elevated
Stowed
8 m (26 ft)
2.3 m (7.5 ft)
Machine Width 1.8 m (5.9 ft)
Machine Length 2.7 m (8.9 ft)
Platform Railing Height 1.1 m (43.5 in.)
Platform Dimensions 2.59 x 1.65 m (8.5 x 5.4 ft)
Platform Capacity 570 kg (1250 lbs)
Platform Extension Capacity 140 kg (300 lbs)
Max Travel Speed 4.5 kmh (2.8 mph)
Max Travel Grade 35%
Max Slope:
S ide to S id e
For e & A ft
3°
5°
Turning Radius:
Inside
O uts id e
2.1 m (6.9 ft)
4.4 m (14.4 ft)
Lift Speed:
Up
D own
32 - 34 sec
21 - 27 secs
Max Tire Load 921 kg (3300 lbs)
Max Ground Bearing Pressure 3.2 kg/cm² (33 psi)
Max Hydraulic system Pressure 20.68 Mpa (3000 psi)
Electrical System Voltage 12 Volt
Wheelbase 2 m (78 in.)
Ground Clearance 20.3 cm (8 in.)
Max Windspeed 12.5 m/s (28 mph)
Max Horizontal Manual Side Force 400 N (90 lbf)
Number of Persons 2
Table 1-2. Capacities
Fuel Tank 27.2 L (7.2 gal)
Hydraulic Oil Tank 56.8 L (15 gal)
Hydraulic System (including tank) 68.1 L (18 gal)
Engine Crankcase:
G aso li ne E ng ine
Diesel Engine
3.25 L (3.4 qts)
4 L (4.2 qts)
Engine Coolant:
Gasoline Engine
Diesel Engine
4.7 L (1.25 gal)
5.7 L (1.5 gal)
Table 1-3. WG750-B Kubota Gasoline/LP
Type 3 cylinder, liquid-cooled
Power 24.5 horsepower @ 3600 rpm
Idle 1500 rpm
High Engine 3600 rpm
Alternator 40 Amp
Fuel Consumption:
Low RP M
Hi gh RP M
4.9 Lph (1.3 gph)
9 Lph (2.4 gph)
Table 1-4. D905-B Kubota Diesel
Type 3 cylinder, liquid-cooled
Power 26 horsepower @ 3000 rpm
Low Idle 800 rpm
High Engine 3800 rpm
Alternator 40 Amp
Fuel Consumption:
Low RP M
H igh RP M
2.6 Lph (0.68 gph)
5.5 Lph (1.48 gph)
