TABLE 18: Indoor AUX
Fault (Displayed Text) Description Category
INDOOR: CONTROL FAIL-
URE
Control failure Critical
INDOOR: LOW VOLTAGE
(<16 VAC)
Low voltage (below 16 VAC) stopped
current relay outputs
Critical
OUTDOOR: LOW VOLT-
AGE(< 19 VAC)
Low voltage (below 19.2 VAC) prevent-
ing further relay outputs
Warning
INDOOR: X/L INPUT-
FLASH 1
X/L Input Status-FLASH 1 Status
INDOOR: X/L INPUT-
FLASH 2
X/L Input Status-FLASH 2 Status
INDOOR: X/L INPUT-
FLASH 3
X/L Input Status-FLASH 3 Status
INDOOR: X/L INPUT-
FLASH 4
X/L Input Status-FLASH 4 Status
INDOOR: X/L INPUT-
FLASH 5
X/L Input Status-FLASH 5 Status
INDOOR: X/L INPUT-
FLASH 6
X/L Input Status-FLASH 6 Status
INDOOR: X/L INPUT-
FLASH 7
X/L Input Status-FLASH 7 Status
INDOOR: X/L INPUT-
FLASH 8
X/L Input Status-FLASH 8 Status
INDOOR: X/L INPUT-
FLASH 9
X/L Input Status-FLASH 9 Status
INDOOR: X/L INPUT-CON-
STANT
N/A Status
