5407934-UIM-C-1119
64 Johnson Controls Ducted Systems
For Variable Capacity systems, users will be able to adjust the Heating
and Cooling airflow by +/- 5 to 10%.
FIGURE 33: Airflow Configuration - 2-Stage AC-HP
FIGURE 34: Airflow Configuration: 1st Stage Cool
2-STAGE AC-HP
1st STAGE HEAT 1150 CFM
2nd STAGE HEAT 1800 CFM
1st STAGE COOL 1210 CFM
AIRFLOW CONFIGURATION
BACK
A1377-001
A1378-001
1100
DEFAULT
StartCancel
1st STAGE COOL
MIN 400 MAX 1860
