5407934-UIM-C-1119
Johnson Controls Ducted Systems 13
FIGURE 8: Variable Capacity Equipment - AC/Heat Pump Control
FIGURE 9: 2-Stage AC/Heat Pump Control
COMMUNICATING
TERMINALS
A0827-002
DO NOT connect indoor equipment "R" connection to this terminal.
COMMUNICATING TERMINALS
A0951-001
