Johnson Controls Hx 3 S1-THXU430W User Manual

5407934-UIM-C-1119
16 Johnson Controls Ducted Systems
FIGURE 10: Variable Capacity - Outdoor Control Housing
COMMUNICATIONS PORT
COMMUNICATIONS HARNESS
(shown through control box and low voltage shield)
OUTDOOR DISPLAY
CONTROL BOARD
A0614-003
DO NOT connect field low voltage
thermostat wiring to this connection.
Use the supplied wiring harness.
PLASTIC CONNECTOR
(cut off plastic connector to connect
thermostat wiring)

Johnson Controls Hx 3 S1-THXU430W Specifications

General

Brand	Johnson Controls
Model	Hx 3 S1-THXU430W
Category	Thermostat
Language	English
