Johnson Controls Hx 3 S1-THXU430W User Manual

5407934-UIM-C-1119
Johnson Controls Ducted Systems 31
POWER-UP
The Auto Setup screen displays on initial power-up. See Figure 21.
SYSTEM CONFIGURATION
When you tap Next on the Auto Setup screen, the thermostat begins a
process to detect the system components and identify the indoor and
outdoor communicating equipment. See Figures 22–25.
FIGURE 21: Power-Up - Auto Setup Screen
NOTICE
If the outdoor unit is a variable capacity model, apply power to the out-
door unit before the indoor unit.
A0622-001
AUTO SETUP
PRESS NEXT TO
BEGIN AUTO SETUP
NEXT
