Table 5: Air handler capacity
Outdoor unit model Air handler model Air handler
width (in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13436B21S JHVTC36DBCC2N1 21.0 — 1050 36.00 25.60 14.75 12.25
RAC13436B21S JMET12BS2N1 17.5 XAFB36D 1175 36.00 26.60 14.25 12.00
RAC13436B21S JMET12BS2N1 17.5 XAFB36E 1150 36.00 26.40 14.25 12.00
RAC13436B21S JMET12BS2N1 17.5 XAUB36D 1175 36.00 26.60 14.25 12.00
RAC13436B21S JMET12BS4N1 17.5 XAFB36D 1225 36.00 27.00 14.25 11.75
RAC13436B21S JMET12BS4N1 17.5 XAFB36E 1225 36.00 27.20 14.25 11.75
RAC13436B21S JMET12BS4N1 17.5 XAUB36D 1225 36.00 27.00 14.25 11.75
RAC13436B21S JMET12CS2N1 21.0 XAFC36D 1100 36.00 26.00 14.50 12.00
RAC13436B21S JMET12CS4N1 21.0 XAFC36D 1000 35.60 25.00 14.50 12.00
RAC13436B21S JMET12CS4N1 21.0 XAFC42E 1000 35.60 25.00 14.75 12.25
RAC13436B21S JMET12CS4N1 21.0 XAHC36D 975 35.40 24.60 14.50 12.00
RAC13436B21S JMET12CS4N1 21.0 XAHC42E 975 35.40 24.60 14.50 12.00
RAC13436B21S JMET12CS4N1 21.0 XAUC42E 1000 35.60 25.00 14.75 12.25
RAC13436B21S RFCB36DBCEMP2N1 17.5 — 1200 36.00 26.80 14.25 11.75
RAC13436B21S RFCC36DBCEMP2N1 21.0 — 1175 36.00 26.60 14.50 12.00
RAC13442B21S JHVTC42FBCC2N1 21.0 — 1250 40.00 29.20 14.50 12.25
RAC13442B21S JHVTD42FBCC2N1 24.5 — 1225 40.00 29.00 14.75 12.25
RAC13442B21S JMET12CS2N1 21.0 XAFC48F 1325 40.50 30.20 14.25 12.00
RAC13442B21S JMET12CS2N1 21.0 XAHC48F 1325 40.50 30.20 14.25 12.00
RAC13442B21S JMET12CS2N1 21.0 XAUC48F 1325 40.50 30.20 14.25 12.00
RAC13442B21S JMET16CS2N1 21.0 XAHC48F 1575 42.00 33.60 14.25 12.20
RAC13442B21S JMET18DS2N1 24.5 XAFD42E 1550 41.00 32.80 14.25 11.75
RAC13442B21S JMET18DS2N1 24.5 XAFD48F 1575 41.00 32.60 14.25 11.75
RAC13442B21S JMET18DS2N1 24.5 XAHD48F 1550 41.00 32.40 14.25 11.75
RAC13442B21S RFCC42FBCEMP2N1 21.0 — 1325 40.50 30.40 14.25 12.00
RAC13448B21S JHVTC48GBCC2N1 21.0 — 1325 47.50 32.40 14.50 12.00
RAC13448B21S JHVTD48GBCC2N1 24.5 — 1400 48.00 33.40 14.50 12.00
RAC13448B21S JMET12CS2N1 21.0 XAFC48F 1325 46.50 31.80 14.25 12.00
RAC13448B21S JMET12CS2N1 21.0 XAFC60G 1350 47.50 32.60 14.25 12.00
RAC13448B21S JMET12CS2N1 21.0 XAHC48F 1325 46.50 31.80 14.25 12.00
RAC13448B21S JMET12CS2N1 21.0 XAHC60G 1350 47.50 32.60 14.50 12.00
RAC13448B21S JMET12CS2N1 21.0 XAUC48F 1325 46.50 31.80 14.25 12.00
RAC13448B21S JMET12CS2N1 21.0 XAUC60G 1350 47.50 32.60 14.25 12.00
RAC13448B21S JMET16CS2N1 21.0 XAFC48F 1575 47.50 34.60 14.00 11.75
RAC13448B21S JMET16CS2N1 21.0 XAFC60G 1600 48.00 35.20 14.25 12.00
RAC13448B21S JMET16CS2N1 21.0 XAHC48F 1575 47.50 34.60 14.00 11.75
RAC13448B21S JMET16CS2N1 21.0 XAHC60G 1600 48.00 35.20 14.25 12.00
RAC13448B21S JMET16CS2N1 21.0 XAUC48F 1575 47.50 34.60 14.00 11.75
RAC13448B21S JMET16CS2N1 21.0 XAUC60G 1600 48.00 35.20 14.25 12.00
RAC13448B21S JMET18DS2N1 24.5 XAFD48F 1575 48.00 34.80 14.25 12.00
RAC13448B21S JMET18DS2N1 24.5 XAFD60G 1575 48.00 34.80 14.25 12.00
RAC13448B21S JMET18DS2N1 24.5 XAHD48F 1550 47.50 34.40 14.25 11.75
RAC13448B21S JMET18DS2N1 24.5 XAHD60G 1550 48.00 34.60 14.25 12.00
RAC13448B21S JMET18DS2N1 24.5 XAUD60G 1575 48.00 34.80 14.25 12.00
RAC13448B21S RFCC48GBCEMP2N1 21.0 — 1575 48.00 34.80 14.25 12.00
RAC13448B21S RFCD48GBCEMP2N1 21.0 — 1375 47.50 32.80 14.50 12.00
RAC13460B21S JHVTC60HBCC2N1 21.0 — 1525 55.00 38.50 14.00 11.75
RAC13460B21S JHVTD60HBCC2N1 24.5 — 1575 55.50 39.00 14.00 11.75
RAC13460B21S JMET16CS2N1 21.0 XAFC60G 1600 55.50 39.00 13.75 11.50
RAC13460B21S JMET16CS2N1 21.0 XAFC60H 1600 55.50 39.50 14.00 11.75
RAC13460B21S JMET16CS2N1 21.0 XAHC60G 1600 55.50 39.00 13.75 11.50
RAC13460B21S JMET16CS2N1 21.0 XAHC60H 1600 55.50 39.50 14.00 11.75
RAC13460B21S JMET16CS2N1 21.0 XAUC60G 1600 55.50 39.00 13.75 11.50
RAC13460B21S JMET18DS2N1 24.5 XAFD60G 1575 55.50 39.00 14.00 11.75
RAC13460B21S JMET18DS2N1 24.5 XAFD60H 1575 55.50 39.00 14.00 11.75
RAC13460B21S JMET18DS2N1 24.5 XAHD60G 1550 55.50 39.00 14.00 11.75
RAC13460B21S JMET18DS2N1 24.5 XAHD60H 1575 55.50 39.00 14.00 11.75
RAC13460B21S JMET18DS2N1 24.5 XAUD60G 1575 55.50 39.00 14.00 11.75
RAC13460B21S JMET18DS2N1 24.5 XAUD60H 1575 55.50 39.00 14.00 11.75
RAC13460B21S RFCC60HBCEMP2N1 24.5 — 1575 55.50 39.00 14.00 11.75
RAC13460B21S RFCD60HBCEMP2N1 24.5 — 1575 55.50 39.00 14.00 11.75
