Table 9: Furnace capacity - 2.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13430B21S TM9Y080B12MP11 21.0 XAFC30C 875 28.80 20.80 14.00 11.75
RAC13430B21S TM9Y080B12MP11 17.5 XAHB30C 850 28.40 20.40 14.00 11.75
RAC13430B21S TM9Y080B12MP11 21.0 XAHC30C 850 28.60 20.60 14.00 11.75
RAC13430B21S TM9Y080B12MP11 21.0 XAHC36D 850 28.40 20.00 14.00 11.75
RAC13430B21S TM9Y080B12MP11 17.5 XAUB30C 875 28.80 20.80 14.00 11.75
RAC13430B21S TM9Y080B12MP11 17.5 XAUB36D 850 28.60 20.20 14.00 11.75
RAC13430B21S TM9Y080C16MP11 21.0 XAFC30C 975 29.20 21.80 14.00 11.75
RAC13430B21S TM9Y080C16MP11 21.0 XAHC30C 975 29.20 21.80 14.00 11.75
RAC13430B21S TM9Y080C16MP11 21.0 XAHC36D 950 29.20 21.20 14.00 11.75
RAC13430B21S TM9Y100C16MP11 21.0 XAFC30C 975 29.20 21.80 14.00 11.75
RAC13430B21S TM9Y100C16MP11 21.0 XAHC30C 950 29.00 21.60 14.00 11.75
RAC13430B21S TM9Y100C16MP11 21.0 XAHC36D 950 29.20 21.20 14.00 11.75
RAC13430B21S TM9Y100C20MP11 21.0 XAFC30C 975 29.20 21.80 14.00 11.75
RAC13430B21S TM9Y100C20MP11 21.0 XAHC30C 950 29.00 21.60 14.00 11.75
RAC13430B21S TM9Y100C20MP11 21.0 XAHC36D 925 29.00 21.00 14.00 11.75
Furnace capacity - 3 ton
Table 10: Furnace capacity - 3 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13436B21S RGF19060AE10MP13 17.5 XAFB36D 1025 35.00 25.20 13.40 11.25
RAC13436B21S RGF19060AE10MP13 17.5 XAFB36E 1025 35.20 25.40 13.40 11.25
RAC13436B21S RGF19060AE10MP13 17.5 XAUB36D 1025 35.00 25.20 13.40 11.25
RAC13436B21S RGF19060BE12MP13 17.5 XAFB36D 950 34.80 24.40 13.75 11.50
RAC13436B21S RGF19060BE12MP13 17.5 XAFB36E 950 34.80 24.40 13.75 11.50
RAC13436B21S RGF19060BE12MP13 21.0 XAFC36D 950 34.80 24.40 13.75 11.50
RAC13436B21S RGF19060BE12MP13 21.0 XAFC42E 950 34.80 24.40 13.75 11.50
RAC13436B21S RGF19060BE12MP13 21.0 XAHC36D 950 34.80 24.40 13.75 11.50
RAC13436B21S RGF19060BE12MP13 21.0 XAHC42E 950 34.80 24.40 13.75 11.50
RAC13436B21S RGF19060BE12MP13 17.5 XAUB36D 950 34.80 24.40 13.75 11.50
RAC13436B21S RGF19060BE12MP13 21.0 XAUC42E 950 34.80 24.40 13.75 11.50
RAC13436B21S RGF19080BE12MP13 17.5 XAFB36D 1100 35.40 26.00 13.50 11.25
RAC13436B21S RGF19080BE12MP13 17.5 XAFB36E 1100 35.60 26.20 13.50 11.25
RAC13436B21S RGF19080BE12MP13 21.0 XAFC36D 1125 35.60 26.20 13.50 11.25
RAC13436B21S RGF19080BE12MP13 21.0 XAFC42E 1125 35.60 26.40 13.75 11.50
RAC13436B21S RGF19080BE12MP13 21.0 XAHC36D 1100 35.40 26.00 13.50 11.25
RAC13436B21S RGF19080BE12MP13 21.0 XAHC42E 1100 35.60 26.20 13.50 11.25
RAC13436B21S RGF19080BE12MP13 17.5 XAUB36D 1100 35.40 26.00 13.50 11.25
RAC13436B21S RGF19080BE12MP13 21.0 XAUC42E 1125 35.60 26.40 13.75 11.50
RAC13436B21S RGF19080CE16MP13 21.0 XAFC36D 1100 35.60 26.00 14.00 11.50
RAC13436B21S RGF19080CE16MP13 21.0 XAFC42E 1100 35.80 26.20 14.00 11.75
RAC13436B21S RGF19080CE16MP13 21.0 XAHC36D 1100 35.60 26.00 14.00 11.50
RAC13436B21S RGF19080CE16MP13 21.0 XAHC42E 1100 35.80 26.20 14.00 11.50
RAC13436B21S RGF19080CE16MP13 21.0 XAUC42E 1100 35.80 26.20 14.00 11.75
RAC13436B21S RGF19080CE20MP13 21.0 XAFC36D 1025 35.60 25.20 14.25 12.00
RAC13436B21S RGF19080CE20MP13 21.0 XAFC42E 1025 35.60 25.20 14.25 12.00
RAC13436B21S RGF19080CE20MP13 21.0 XAHC36D 1000 35.40 25.00 14.25 11.75
RAC13436B21S RGF19080CE20MP13 21.0 XAHC42E 1000 35.40 25.00 14.25 11.75
RAC13436B21S RGF19080CE20MP13 21.0 XAUC42E 1025 35.60 25.20 14.25 12.00
RAC13436B21S RGF19100CE16MP13 21.0 XAFC36D 1100 35.80 26.00 14.00 11.50
RAC13436B21S RGF19100CE16MP13 21.0 XAFC42E 1125 35.80 26.40 14.00 11.75
RAC13436B21S RGF19100CE16MP13 21.0 XAHC36D 1100 35.60 26.00 14.00 11.50
RAC13436B21S RGF19100CE16MP13 21.0 XAHC42E 1100 35.80 26.20 14.00 11.50
RAC13436B21S RGF19100CE16MP13 21.0 XAUC42E 1125 35.80 26.40 14.00 11.75
RAC13436B21S RGF19100CE20MP13 21.0 XAFC36D 1000 35.40 25.00 14.25 12.00
RAC13436B21S RGF19100CE20MP13 21.0 XAFC42E 1000 35.40 25.00 14.25 12.00
RAC13436B21S RGF19100CE20MP13 21.0 XAHC36D 975 35.20 24.60 14.25 11.75
RAC13436B21S RGF19100CE20MP13 21.0 XAHC42E 975 35.40 24.80 14.25 11.75
RAC13436B21S RGF19100CE20MP13 21.0 XAUC42E 1000 35.40 25.00 14.25 12.00
RAC13436B21S RGF1L040AE12MP12 17.5 XAFB36D 1075 35.60 25.80 13.75 11.50
25Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
