Multipliers for determining the performance with other
indoor sections
Note: For dry bulb temperatures different than those listed (between 73°F to 87°F), sensible
capacity increases by 1060 Btu/h per 1000 CFM per degree above the listed temperature and
decreases by 1060 Btu/h per 1000 CFM per degree below the listed temperature.
Cool multiplier air handler - 2.5 ton
Table 26: Cool multiplier air handler - 2.5 ton
Air handler model Indoor coil model Total capacity Sensible capacity kW
— XAFA30D 0.98 0.92 0.98
— XAFB30C 1.00 1.00 1.00
— XAFB36D 1.00 0.98 1.00
— XAFC30C 1.00 1.00 1.00
— XAFC36D 1.00 0.99 1.00
— XAHB30C 1.00 1.00 1.00
— XAHC30C 1.00 1.00 1.00
— XAHC36D 1.00 0.98 1.00
— XAUB30C 1.00 1.00 1.00
— XAUB36D 1.00 0.98 1.00
JHVTB36DBAC2N1 — 0.99 0.91 0.93
JHVTC36DBAC2N1 — 1.03 1.01 0.95
JMET12BS2N1 XAFB30C 0.99 0.91 0.91
JMET12BS2N1 XAFB36D 1.03 1.05 0.97
JMET12BS2N1 XAHB30C 1.03 1.06 0.98
JMET12BS2N1 XAUB30C 0.99 0.91 0.91
JMET12BS2N1 XAUB36D 1.03 1.05 0.97
JMET12CS2N1 XAFC30C 1.02 0.98 0.94
JMET12CS2N1 XAHC30C 1.01 0.97 0.95
JMET12CS2N1 XAHC36D 1.01 0.95 0.93
JMET16CS2N1 XAFC30C 1.02 0.98 0.94
JMET16CS2N1 XAHC30C 1.01 0.97 0.93
JMET16CS2N1 XAHC36D 1.01 0.95 0.93
RFCB30DBAEMP2N1 — 1.02 0.97 0.96
RFCB36DBAEMP2N1 — 1.03 1.05 0.99
RFCC36DBAEMP2N1 — 0.99 0.90 0.91
Cool multiplier furnace - 2.5 ton
Table 27: Cool multiplier furnace - 2.5 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
RGF19040AE10MP13 XAFB30C 0.99 0.96 0.99
RGF19040AE10MP13 XAFB36D 0.99 0.93 0.99
RGF19040AE10MP13 XAHB30C 0.98 0.94 0.98
RGF19040AE10MP13 XAUB30C 0.99 0.96 0.99
RGF19040AE10MP13 XAUB36D 0.99 0.93 0.99
RGF19060AE10MP13 XAFB30C 0.99 0.96 0.97
RGF19060AE10MP13 XAFB36D 0.99 0.95 0.97
RGF19060AE10MP13 XAHB30C 0.99 0.95 0.99
RGF19060AE10MP13 XAUB30C 0.99 0.96 0.97
RGF19060AE10MP13 XAUB36D 0.99 0.95 0.97
RGF19060BE12MP13 XAFB30C 0.99 0.93 0.95
RGF19060BE12MP13 XAFB36D 0.99 0.90 0.94
