Johnson Controls RAC Series User Manual

Table 11: Furnace capacity - 3.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13442B21S TM9Y080C16MP11 21.0 XAFC42E 1250 41.00 30.80 14.00 11.75
RAC13442B21S TM9Y080C16MP11 21.0 XAFC48F 1250 41.00 30.40 14.00 11.75
RAC13442B21S TM9Y080C16MP11 24.5 XAFD42E 1250 40.50 30.40 14.00 11.75
RAC13442B21S TM9Y080C16MP11 24.5 XAFD48F 1275 40.50 30.20 14.00 12.20
RAC13442B21S TM9Y080C16MP11 21.0 XAHC42E 1225 40.50 30.20 13.75 11.75
RAC13442B21S TM9Y080C16MP11 21.0 XAHC48F 1275 41.00 30.60 14.00 12.20
RAC13442B21S TM9Y080C16MP11 24.5 XAHD42E 1250 40.50 30.40 13.75 11.75
RAC13442B21S TM9Y080C16MP11 24.5 XAHD48F 1275 40.50 30.20 14.00 12.20
RAC13442B21S TM9Y080C16MP11 21.0 XAUC42E 1250 41.00 30.80 14.00 11.75
RAC13442B21S TM9Y080C16MP11 21.0 XAUC48F 1250 41.00 30.40 14.00 11.75
RAC13442B21S TM9Y100C16MP11 21.0 XAFC42E 1250 41.00 30.80 13.75 11.75
RAC13442B21S TM9Y100C16MP11 21.0 XAFC48F 1250 41.00 30.40 14.00 11.75
RAC13442B21S TM9Y100C16MP11 24.5 XAFD42E 1250 40.50 30.40 14.00 11.75
RAC13442B21S TM9Y100C16MP11 24.5 XAFD48F 1275 40.50 30.20 14.00 12.20
RAC13442B21S TM9Y100C16MP11 21.0 XAHC42E 1225 40.50 30.20 13.75 11.75
RAC13442B21S TM9Y100C16MP11 21.0 XAHC48F 1275 41.00 30.60 14.00 12.20
RAC13442B21S TM9Y100C16MP11 24.5 XAHD42E 1250 40.50 30.40 13.75 11.75
RAC13442B21S TM9Y100C16MP11 24.5 XAHD48F 1275 40.50 30.20 14.00 12.20
RAC13442B21S TM9Y100C16MP11 21.0 XAUC42E 1250 41.00 30.80 13.75 11.75
RAC13442B21S TM9Y100C16MP11 21.0 XAUC48F 1250 41.00 30.40 14.00 11.75
RAC13442B21S TM9Y100C20MP11 21.0 XAFC42E 1350 41.00 31.60 13.75 11.75
RAC13442B21S TM9Y100C20MP11 21.0 XAFC48F 1375 41.00 31.40 13.75 11.75
RAC13442B21S TM9Y100C20MP11 24.5 XAFD42E 1375 40.50 31.40 13.75 11.75
RAC13442B21S TM9Y100C20MP11 24.5 XAFD48F 1400 41.00 31.60 13.75 11.75
RAC13442B21S TM9Y100C20MP11 21.0 XAHC42E 1325 41.00 31.60 13.75 11.75
RAC13442B21S TM9Y100C20MP11 21.0 XAHC48F 1375 41.00 31.40 13.75 11.75
RAC13442B21S TM9Y100C20MP11 24.5 XAHD42E 1350 40.50 31.20 13.75 11.75
RAC13442B21S TM9Y100C20MP11 24.5 XAHD48F 1375 40.50 31.00 13.75 11.75
RAC13442B21S TM9Y100C20MP11 21.0 XAUC42E 1350 41.00 31.60 13.75 11.75
RAC13442B21S TM9Y100C20MP11 21.0 XAUC48F 1375 41.00 31.40 13.75 11.75
RAC13442B21S TM9Y120D20MP11 24.5 XAFD42E 1225 40.00 29.60 14.25 11.75
RAC13442B21S TM9Y120D20MP11 24.5 XAFD48F 1225 40.00 29.40 14.25 11.75
RAC13442B21S TM9Y120D20MP11 24.5 XAHD42E 1200 40.00 29.40 14.00 11.75
RAC13442B21S TM9Y120D20MP11 24.5 XAHD48F 1225 40.00 29.40 14.25 11.75
Furnace capacity - 4 ton
Table 12: Furnace capacity - 4 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13448B21S RGF19080CE16MP13 21.0 XAFC48F 1425 46.50 33.00 13.50 11.25
RAC13448B21S RGF19080CE16MP13 21.0 XAFC60G 1450 47.50 33.80 13.75 11.50
RAC13448B21S RGF19080CE16MP13 24.5 XAFD48F 1425 46.50 33.00 13.50 11.25
RAC13448B21S RGF19080CE16MP13 24.5 XAFD60G 1450 47.50 33.80 13.75 11.50
RAC13448B21S RGF19080CE16MP13 21.0 XAHC48F 1425 46.50 33.00 13.50 11.25
RAC13448B21S RGF19080CE16MP13 21.0 XAHC60G 1450 47.50 33.80 13.75 11.50
RAC13448B21S RGF19080CE16MP13 24.5 XAHD48F 1425 46.50 33.00 13.50 11.25
RAC13448B21S RGF19080CE16MP13 21.0 XAHD60G 1425 47.50 33.60 13.75 11.50
RAC13448B21S RGF19080CE16MP13 21.0 XAUC48F 1425 46.50 33.00 13.50 11.25
RAC13448B21S RGF19080CE16MP13 21.0 XAUC60G 1450 47.50 33.80 13.75 11.50
RAC13448B21S RGF19080CE16MP13 24.5 XAUD60G 1450 47.50 33.80 13.75 11.50
RAC13448B21S RGF19080CE20MP13 21.0 XAFC48F 1350 46.00 32.00 13.75 11.50
RAC13448B21S RGF19080CE20MP13 21.0 XAFC60G 1375 47.50 33.00 14.25 11.75
RAC13448B21S RGF19080CE20MP13 24.5 XAFD48F 1375 46.50 32.40 14.00 11.75
RAC13448B21S RGF19080CE20MP13 24.5 XAFD60G 1375 47.50 33.00 14.25 11.75
RAC13448B21S RGF19080CE20MP13 21.0 XAHC48F 1350 46.00 32.00 13.75 11.50
RAC13448B21S RGF19080CE20MP13 21.0 XAHC60G 1375 47.50 33.00 14.25 12.00
RAC13448B21S RGF19080CE20MP13 24.5 XAHD48F 1350 46.00 32.00 13.75 11.50
RAC13448B21S RGF19080CE20MP13 21.0 XAHD60G 1350 47.00 32.60 14.00 11.75
RAC13448B21S RGF19080CE20MP13 21.0 XAUC48F 1350 46.00 32.00 13.75 11.50
RAC13448B21S RGF19080CE20MP13 21.0 XAUC60G 1375 47.50 33.00 14.25 11.75
Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase34
Johnson Controls Ducted Systems

Johnson Controls RAC Series Specifications
