Table 13: Furnace capacity - 5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13460B21S RL18120C16MPS1 21.0 XAHD60G 1850 55.50 41.50 13.40 11.25
RAC13460B21S RL18120C16MPS1 24.5 XAHD60H 1550 54.50 38.50 13.75 11.50
RAC13460B21S RL18120C16MPS1 21.0 XAUC60G 1550 54.50 38.50 13.50 11.50
RAC13460B21S RL18120C16MPS1 24.5 XAUD60G 1550 54.50 38.50 13.50 11.50
RAC13460B21S RL18120C16MPS1 24.5 XAUD60H 1550 54.50 38.50 13.75 11.50
RAC13460B21S RL18120C20MPS1 21.0 XAFC60G 1575 54.50 38.50 13.40 11.25
RAC13460B21S RL18120C20MPS1 21.0 XAFC60H 1600 55.00 39.50 13.50 11.25
RAC13460B21S RL18120C20MPS1 24.5 XAFD60G 1600 55.00 39.00 13.40 11.25
RAC13460B21S RL18120C20MPS1 24.5 XAFD60H 1575 54.50 39.00 13.50 11.25
RAC13460B21S RL18120C20MPS1 21.0 XAHC60G 1600 55.00 39.00 13.40 11.25
RAC13460B21S RL18120C20MPS1 21.0 XAHC60H 1600 55.00 39.50 13.50 11.25
RAC13460B21S RL18120C20MPS1 21.0 XAHD60G 1575 54.50 38.50 13.40 11.25
RAC13460B21S RL18120C20MPS1 24.5 XAHD60H 1575 54.50 39.00 13.50 11.25
RAC13460B21S RL18120C20MPS1 21.0 XAUC60G 1575 54.50 38.50 13.40 11.25
RAC13460B21S RL18120C20MPS1 24.5 XAUD60G 1600 55.00 39.00 13.40 11.25
RAC13460B21S RL18120C20MPS1 24.5 XAUD60H 1575 54.50 39.00 13.50 11.25
RAC13460B21S RL18130D20MPS1 24.5 XAFD60G 1550 54.50 38.50 13.50 11.50
RAC13460B21S RL18130D20MPS1 24.5 XAFD60H 1775 56.00 41.50 13.75 11.50
RAC13460B21S RL18130D20MPS1 21.0 XAHD60G 1750 56.00 41.00 13.50 11.50
RAC13460B21S RL18130D20MPS1 24.5 XAHD60H 1750 56.00 41.00 13.75 11.50
RAC13460B21S RL18130D20MPS1 24.5 XAUD60G 1550 54.50 38.50 13.50 11.50
RAC13460B21S RL18130D20MPS1 24.5 XAUD60H 1775 56.00 41.50 13.75 11.50
RAC13460B21S TM8Y100C20MP11 21.0 XAFC60G 1725 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y100C20MP11 21.0 XAFC60H 1725 55.50 41.00 13.40 11.00
RAC13460B21S TM8Y100C20MP11 24.5 XAFD60G 1750 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y100C20MP11 21.0 XAHC60G 1725 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y100C20MP11 21.0 XAHC60H 1725 55.50 41.00 13.40 11.00
RAC13460B21S TM8Y100C20MP11 21.0 XAHD60G 1700 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y100C20MP11 21.0 XAUC60G 1725 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y100C20MP11 24.5 XAUD60G 1750 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y120C20MP11 21.0 XAFC60G 1725 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y120C20MP11 21.0 XAFC60H 1725 55.50 41.00 13.40 11.00
RAC13460B21S TM8Y120C20MP11 24.5 XAFD60G 1750 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y120C20MP11 21.0 XAHC60G 1725 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y120C20MP11 21.0 XAHC60H 1725 55.50 41.00 13.40 11.00
RAC13460B21S TM8Y120C20MP11 21.0 XAHD60G 1700 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y120C20MP11 21.0 XAUC60G 1725 55.50 40.50 13.40 11.00
RAC13460B21S TM8Y120C20MP11 24.5 XAUD60G 1750 55.50 40.50 13.40 11.00
RAC13460B21S TM9Y100C20MP11 21.0 XAFC60G 1575 55.00 39.00 13.40 11.00
RAC13460B21S TM9Y100C20MP11 21.0 XAFC60H 1575 55.00 39.50 13.40 11.00
RAC13460B21S TM9Y100C20MP11 24.5 XAFD60G 1575 55.00 39.00 13.40 11.00
RAC13460B21S TM9Y100C20MP11 24.5 XAFD60H 1575 55.00 39.50 13.40 11.00
RAC13460B21S TM9Y100C20MP11 21.0 XAHC60G 1575 55.00 39.00 13.40 11.00
RAC13460B21S TM9Y100C20MP11 21.0 XAHC60H 1600 55.00 39.50 13.40 11.00
RAC13460B21S TM9Y100C20MP11 21.0 XAHD60G 1525 54.50 38.50 13.40 11.00
RAC13460B21S TM9Y100C20MP11 24.5 XAHD60H 1550 54.50 39.00 13.40 11.00
RAC13460B21S TM9Y100C20MP11 21.0 XAUC60G 1575 55.00 39.00 13.40 11.00
RAC13460B21S TM9Y100C20MP11 24.5 XAUD60G 1575 55.00 39.00 13.40 11.00
RAC13460B21S TM9Y100C20MP11 24.5 XAUD60H 1575 55.00 39.50 13.40 11.00
RAC13460B21S TM9Y120D20MP11 24.5 XAFD60G 1700 55.50 40.50 13.40 11.00
RAC13460B21S TM9Y120D20MP11 24.5 XAFD60H 1675 55.00 40.00 13.40 11.00
RAC13460B21S TM9Y120D20MP11 21.0 XAHD60G 1650 55.00 39.50 13.40 11.00
RAC13460B21S TM9Y120D20MP11 24.5 XAHD60H 1675 55.00 40.00 13.40 11.00
RAC13460B21S TM9Y120D20MP11 24.5 XAUD60G 1700 55.50 40.50 13.40 11.00
RAC13460B21S TM9Y120D20MP11 24.5 XAUD60H 1675 55.00 40.00 13.40 11.00
Furnace capacity data notes
• For rated condition information, see Air handler capacity data notes.
• High-efficiency motor furnaces have blower off delay (BOD) standard.
• PSC furnaces use coil only ratings.
41Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
