Table 10: Furnace capacity - 3 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13436B21S TM8Y100C20MP11 21.0 XAUC42E 1000 35.40 25.00 14.50 12.00
RAC13436B21S TM8Y120C20MP11 21.0 XAFC36D 1000 35.40 25.00 14.50 12.00
RAC13436B21S TM8Y120C20MP11 21.0 XAFC42E 1000 35.40 25.00 14.50 12.00
RAC13436B21S TM8Y120C20MP11 24.5 XAFD42E 1000 35.00 24.80 14.25 11.75
RAC13436B21S TM8Y120C20MP11 21.0 XAHC36D 975 35.20 24.60 14.25 12.00
RAC13436B21S TM8Y120C20MP11 21.0 XAHC42E 975 35.40 24.80 14.25 12.00
RAC13436B21S TM8Y120C20MP11 24.5 XAHD42E 1175 35.80 26.80 13.75 11.50
RAC13436B21S TM8Y120C20MP11 21.0 XAUC42E 1000 35.40 25.00 14.50 12.00
RAC13436B21S TM9Y060B12MP11 17.5 XAFB36D 1000 35.00 24.80 13.50 11.25
RAC13436B21S TM9Y060B12MP11 17.5 XAFB36E 975 35.00 24.80 13.40 11.25
RAC13436B21S TM9Y060B12MP11 21.0 XAFC36D 1000 35.00 24.80 13.50 11.25
RAC13436B21S TM9Y060B12MP11 21.0 XAFC42E 1000 35.20 25.00 13.50 11.25
RAC13436B21S TM9Y060B12MP11 21.0 XAHC36D 1000 35.00 24.80 13.50 11.25
RAC13436B21S TM9Y060B12MP11 21.0 XAHC42E 975 35.00 24.80 13.40 11.25
RAC13436B21S TM9Y060B12MP11 17.5 XAUB36D 1000 35.00 24.80 13.50 11.25
RAC13436B21S TM9Y060B12MP11 21.0 XAUC42E 1000 35.20 25.00 13.50 11.25
RAC13436B21S TM9Y080B12MP11 17.5 XAFB36D 1025 35.20 25.20 13.75 11.50
RAC13436B21S TM9Y080B12MP11 17.5 XAFB36E 1025 35.20 25.20 13.75 11.50
RAC13436B21S TM9Y080B12MP11 21.0 XAFC36D 1050 35.40 25.60 13.75 11.50
RAC13436B21S TM9Y080B12MP11 21.0 XAFC42E 1050 35.40 25.60 13.75 11.50
RAC13436B21S TM9Y080B12MP11 21.0 XAHC36D 1025 35.20 25.20 13.75 11.50
RAC13436B21S TM9Y080B12MP11 21.0 XAHC42E 1025 35.20 25.20 13.75 11.50
RAC13436B21S TM9Y080B12MP11 17.5 XAUB36D 1025 35.20 25.20 13.75 11.50
RAC13436B21S TM9Y080B12MP11 21.0 XAUC42E 1050 35.40 25.60 13.75 11.50
RAC13436B21S TM9Y080C16MP11 21.0 XAFC36D 950 35.00 24.40 14.00 11.75
RAC13436B21S TM9Y080C16MP11 21.0 XAFC42E 975 35.20 24.60 14.25 11.75
RAC13436B21S TM9Y080C16MP11 21.0 XAHC36D 950 35.00 24.40 14.00 11.75
RAC13436B21S TM9Y080C16MP11 21.0 XAHC42E 950 35.00 24.40 14.00 11.75
RAC13436B21S TM9Y080C16MP11 21.0 XAUC42E 975 35.20 24.60 14.25 11.75
RAC13436B21S TM9Y100C16MP11 21.0 XAFC36D 950 35.00 24.40 14.00 11.75
RAC13436B21S TM9Y100C16MP11 21.0 XAFC42E 950 35.00 24.40 14.00 11.75
RAC13436B21S TM9Y100C16MP11 21.0 XAHC36D 950 35.00 24.40 14.00 11.75
RAC13436B21S TM9Y100C16MP11 21.0 XAHC42E 1075 35.60 25.80 13.75 11.50
RAC13436B21S TM9Y100C16MP11 21.0 XAUC42E 950 35.00 24.40 14.00 11.75
RAC13436B21S TM9Y100C20MP11 21.0 XAFC36D 950 35.00 24.40 14.00 11.75
RAC13436B21S TM9Y100C20MP11 21.0 XAFC42E 950 35.00 24.40 14.00 11.75
RAC13436B21S TM9Y100C20MP11 21.0 XAHC36D 1125 35.60 26.20 13.75 11.50
RAC13436B21S TM9Y100C20MP11 21.0 XAHC42E 1125 35.60 26.20 13.75 11.50
RAC13436B21S TM9Y100C20MP11 21.0 XAUC42E 950 35.00 24.40 14.00 11.75
Furnace capacity - 3.5 ton
Table 11: Furnace capacity - 3.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13442B21S RGF19080BE12MP13 21.0 XAFC42E 1200 40.00 29.80 13.75 11.75
RAC13442B21S RGF19080BE12MP13 21.0 XAFC48F 1225 40.00 29.60 13.75 11.75
RAC13442B21S RGF19080BE12MP13 21.0 XAHC42E 1200 40.00 29.80 13.75 11.75
RAC13442B21S RGF19080BE12MP13 21.0 XAHC48F 1225 40.00 29.60 13.75 11.75
RAC13442B21S RGF19080BE12MP13 21.0 XAUC42E 1200 40.00 29.80 13.75 11.75
RAC13442B21S RGF19080BE12MP13 21.0 XAUC48F 1225 40.00 29.60 13.75 11.75
RAC13442B21S RGF19080CE16MP13 21.0 XAFC42E 1400 41.50 32.40 13.75 11.75
RAC13442B21S RGF19080CE16MP13 21.0 XAFC48F 1425 41.50 32.20 13.75 11.75
RAC13442B21S RGF19080CE16MP13 24.5 XAFD42E 1425 41.00 32.20 13.75 11.75
RAC13442B21S RGF19080CE16MP13 24.5 XAFD48F 1425 41.00 31.80 13.75 11.75
RAC13442B21S RGF19080CE16MP13 21.0 XAHC42E 1350 41.50 32.00 14.00 12.20
RAC13442B21S RGF19080CE16MP13 21.0 XAHC48F 1425 41.50 32.20 13.75 11.75
RAC13442B21S RGF19080CE16MP13 24.5 XAHD42E 1375 41.00 31.80 14.00 11.75
RAC13442B21S RGF19080CE16MP13 24.5 XAHD48F 1425 41.00 31.80 13.75 11.75
RAC13442B21S RGF19080CE16MP13 21.0 XAUC42E 1400 41.50 32.40 13.75 11.75
RAC13442B21S RGF19080CE16MP13 21.0 XAUC48F 1425 41.50 32.20 13.75 11.75
29Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
Johnson Controls Ducted Systems
