Air handler capacity data notes
• Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and
ANSI/AHRI Standard 210/240.
• The cooling MBH is based on 80°F entering air temperature, 50% relative humidity (RH), and
rated airflow.
• The energy efficiency ratio (EER2) is the total cooling output in BTUs at 95°F outdoor ambient
divided by the total electric power in watt-hours at those conditions.
• The seasonal energy efficiency ratio (SEER2) is the total cooling output in BTUs during a normal
annual usage period for cooling divided by the total electric power input in watt-hours during
the same period.
• A cell with no value means not applicable.
Coil only capacity
Table 6: Coil only capacity
Outdoor unit model Indoor coil model Indoor coil
width (in.)
CFM range Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13418B21S XAFA18A 14.5 450—750 600 18.00 13.20 13.40 11.25
RAC13418B21S XAFA24B 14.5 450—750 600 18.00 13.30 13.40 11.25
RAC13418B21S XAFB18A 17.5 450—750 600 18.00 13.20 13.40 11.25
RAC13418B21S XAFB24B 17.5 450—750 600 18.00 13.30 13.40 11.25
RAC13418B21S XAHA18A 14.5 450—750 600 18.00 13.20 13.40 11.25
RAC13418B21S XAHA24B 14.5 450—750 600 18.00 13.30 13.40 11.25
RAC13418B21S XAHB24B 17.5 450—750 600 18.00 13.30 13.40 11.25
RAC13418B21S XAUA18A 14.5 450—750 600 18.00 13.20 13.40 11.25
RAC13418B21S XAUA24B 14.5 450—750 600 18.00 13.30 13.40 11.25
RAC13424B21S XAFA24B 14.5 600—1000 800 23.80 17.60 13.40 11.25
RAC13424B21S XAFB24B 17.5 600—1000 800 24.00 17.70 13.40 11.50
RAC13424B21S XAFB30C 17.5 600—1000 800 24.00 18.10 13.50 11.50
RAC13424B21S XAFC30C 21.0 600—1000 800 24.00 18.10 13.50 11.50
RAC13424B21S XAHA24B 14.5 600—1000 800 24.00 17.70 13.40 11.50
RAC13424B21S XAHB24B 17.5 600—1000 800 24.00 17.70 13.40 11.50
RAC13424B21S XAHB30C 17.5 600—1000 800 24.00 18.10 13.50 11.50
RAC13424B21S XAHC30C 21.0 600—1000 800 24.00 18.10 13.50 11.50
RAC13424B21S XAUA24B 14.5 600—1000 800 23.80 17.60 13.40 11.25
RAC13424B21S XAUB30C 17.5 600—1000 800 24.00 18.10 13.50 11.50
RAC13430B21S XAFA30D 14.5 800—1200 850 28.20 20.20 13.40 11.25
RAC13430B21S XAFB30C 17.5 800—1200 1000 28.80 22.00 13.40 11.25
RAC13430B21S XAFB36D 17.5 800—1200 1000 28.80 21.60 13.40 11.25
RAC13430B21S XAFC30C 21.0 800—1200 1000 28.80 22.00 13.40 11.25
RAC13430B21S XAFC36D 21.0 800—1200 1000 28.80 21.80 13.40 11.25
RAC13430B21S XAHB30C 17.5 800—1200 1000 28.80 22.00 13.40 11.25
RAC13430B21S XAHC30C 21.0 800—1200 1000 28.80 22.00 13.40 11.25
RAC13430B21S XAHC36D 21.0 800—1200 1000 28.80 21.60 13.40 11.25
RAC13430B21S XAUB30C 17.5 800—1200 1000 28.80 22.00 13.40 11.25
RAC13430B21S XAUB36D 17.5 800—1200 1000 28.80 21.60 13.40 11.25
RAC13436B21S XAFB36D 17.5 1000—1400 1150 35.40 26.40 13.40 11.25
RAC13436B21S XAFB36E 17.5 1000—1400 1100 35.40 26.20 13.40 11.25
RAC13436B21S XAFC36D 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
RAC13436B21S XAFC42E 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
RAC13436B21S XAFD42E 24.5 1000—1400 1150 35.40 26.60 13.40 11.25
RAC13436B21S XAHC36D 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
RAC13436B21S XAHC42E 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
RAC13436B21S XAHD42E 24.5 1000—1400 1150 35.40 26.60 13.40 11.25
RAC13436B21S XAUB36D 17.5 1000—1400 1150 35.40 26.40 13.40 11.25
RAC13436B21S XAUC42E 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
RAC13442B21S XAFC42E 21.0 1200—1600 1400 40.00 31.40 13.40 11.25
RAC13442B21S XAFC48F 21.0 1200—1600 1400 41.00 31.80 13.50 11.50
15Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
