Table 8: Furnace capacity - 2 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13424B21S TM8Y080B12MP11 17.5 XAUB30C 675 23.80 16.70 14.75 12.25
RAC13424B21S TM8Y080C16MP11 21.0 XAFC30C 775 24.00 17.50 14.75 12.25
RAC13424B21S TM8Y080C16MP11 21.0 XAHC30C 775 24.00 17.50 14.75 12.25
RAC13424B21S TM8Y100C16MP11 21.0 XAFC30C 775 24.00 17.50 14.75 12.25
RAC13424B21S TM8Y100C16MP11 21.0 XAHC30C 775 24.00 17.50 14.75 12.25
RAC13424B21S TM8Y100C20MP11 21.0 XAFC30C 775 24.00 17.50 14.75 12.25
RAC13424B21S TM8Y100C20MP11 21.0 XAHC30C 750 24.00 17.40 14.75 12.25
RAC13424B21S TM8Y120C20MP11 21.0 XAFC30C 775 24.00 17.50 14.75 12.25
RAC13424B21S TM8Y120C20MP11 21.0 XAHC30C 750 24.00 17.40 14.75 12.25
RAC13424B21S TM9Y060B12MP11 17.5 XAFB24B 725 24.00 17.00 14.00 12.00
RAC13424B21S TM9Y060B12MP11 17.5 XAFB30C 725 24.00 17.30 14.50 12.00
RAC13424B21S TM9Y060B12MP11 21.0 XAFC30C 725 23.80 17.10 14.50 12.00
RAC13424B21S TM9Y060B12MP11 17.5 XAHB24B 700 24.00 16.80 14.00 11.75
RAC13424B21S TM9Y060B12MP11 17.5 XAHB30C 700 24.00 17.10 14.25 12.00
RAC13424B21S TM9Y060B12MP11 21.0 XAHC30C 725 23.80 17.10 14.25 12.00
RAC13424B21S TM9Y060B12MP11 17.5 XAUB30C 725 24.00 17.30 14.50 12.00
RAC13424B21S TM9Y080B12MP11 17.5 XAFB24B 750 24.00 17.10 14.00 12.00
RAC13424B21S TM9Y080B12MP11 17.5 XAFB30C 750 24.00 17.40 14.50 12.00
RAC13424B21S TM9Y080B12MP11 21.0 XAFC30C 750 23.80 17.30 14.50 12.00
RAC13424B21S TM9Y080B12MP11 17.5 XAHB24B 750 24.00 17.10 14.00 12.00
RAC13424B21S TM9Y080B12MP11 17.5 XAHB30C 750 24.00 17.40 14.50 12.00
RAC13424B21S TM9Y080B12MP11 21.0 XAHC30C 750 23.80 17.30 14.50 12.00
RAC13424B21S TM9Y080B12MP11 17.5 XAUB30C 750 24.00 17.40 14.50 12.00
RAC13424B21S TM9Y080C16MP11 21.0 XAFC30C 775 24.00 17.60 14.50 12.00
RAC13424B21S TM9Y080C16MP11 21.0 XAHC30C 775 24.00 17.60 14.50 12.00
RAC13424B21S TM9Y100C16MP11 21.0 XAFC30C 775 24.00 17.60 14.50 12.25
RAC13424B21S TM9Y100C16MP11 21.0 XAHC30C 750 24.00 17.40 14.50 12.00
RAC13424B21S TM9Y100C20MP11 21.0 XAHC30C 950 24.00 18.90 14.00 12.00
Furnace capacity - 2.5 ton
Table 9: Furnace capacity - 2.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13430B21S RGF19040AE10MP13 17.5 XAFB30C 925 28.60 21.20 13.40 11.25
RAC13430B21S RGF19040AE10MP13 17.5 XAFB36D 875 28.40 20.40 13.40 11.25
RAC13430B21S RGF19040AE10MP13 17.5 XAHB30C 875 28.20 20.60 13.40 11.25
RAC13430B21S RGF19040AE10MP13 17.5 XAUB30C 925 28.60 21.20 13.40 11.25
RAC13430B21S RGF19040AE10MP13 17.5 XAUB36D 875 28.40 20.40 13.40 11.25
RAC13430B21S RGF19060AE10MP13 17.5 XAFB30C 925 28.60 21.20 13.50 11.50
RAC13430B21S RGF19060AE10MP13 17.5 XAFB36D 925 28.60 20.80 13.50 11.50
RAC13430B21S RGF19060AE10MP13 17.5 XAHB30C 900 28.40 21.00 13.40 11.25
RAC13430B21S RGF19060AE10MP13 17.5 XAUB30C 925 28.60 21.20 13.50 11.50
RAC13430B21S RGF19060AE10MP13 17.5 XAUB36D 925 28.60 20.80 13.50 11.50
RAC13430B21S RGF19060BE12MP13 17.5 XAFB30C 825 28.60 20.40 14.00 11.75
RAC13430B21S RGF19060BE12MP13 17.5 XAFB36D 800 28.40 19.70 14.00 11.75
RAC13430B21S RGF19060BE12MP13 21.0 XAFC30C 825 28.60 20.40 14.00 11.75
RAC13430B21S RGF19060BE12MP13 17.5 XAHB30C 800 28.40 20.00 14.00 11.75
RAC13430B21S RGF19060BE12MP13 21.0 XAHC30C 800 28.40 20.00 14.00 11.75
RAC13430B21S RGF19060BE12MP13 21.0 XAHC36D 800 28.40 19.70 14.00 11.75
RAC13430B21S RGF19060BE12MP13 17.5 XAUB30C 825 28.60 20.40 14.00 11.75
RAC13430B21S RGF19060BE12MP13 17.5 XAUB36D 800 28.40 19.70 14.00 11.75
RAC13430B21S RGF19080BE12MP13 17.5 XAFB30C 925 29.00 21.40 14.00 11.75
RAC13430B21S RGF19080BE12MP13 17.5 XAFB36D 900 28.80 20.80 14.00 11.75
RAC13430B21S RGF19080BE12MP13 21.0 XAFC30C 925 29.00 21.40 14.00 11.75
RAC13430B21S RGF19080BE12MP13 17.5 XAHB30C 900 28.80 21.00 13.75 11.50
RAC13430B21S RGF19080BE12MP13 21.0 XAHC30C 925 29.00 21.40 14.00 11.75
RAC13430B21S RGF19080BE12MP13 21.0 XAHC36D 900 28.80 20.80 14.00 11.75
RAC13430B21S RGF19080BE12MP13 17.5 XAUB30C 925 29.00 21.40 14.00 11.75
RAC13430B21S RGF19080BE12MP13 17.5 XAUB36D 900 28.80 20.80 14.00 11.75
RAC13430B21S RGF19080CE16MP13 21.0 XAFC30C 925 29.20 21.40 14.25 12.00
21Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
