Johnson Controls RAC Series User Manual

Table 27: Cool multiplier furnace - 2.5 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
TM9Y080C16MP11 XAHC36D 1.01 0.96 0.97
TM9Y100C16MP11 XAFC30C 1.01 0.99 0.97
TM9Y100C16MP11 XAHC30C 1.01 0.98 0.96
TM9Y100C16MP11 XAHC36D 1.01 0.96 0.97
TM9Y100C20MP11 XAFC30C 1.01 0.99 0.97
TM9Y100C20MP11 XAHC30C 1.01 0.98 0.96
TM9Y100C20MP11 XAHC36D 1.01 0.95 0.96
Performance data - 3 ton
See the following tables for performance and multiplier data for the RAC13436B21S unit.
Condenser only performance data - 3 ton
Table 28: Condenser only performance data - 3 ton
Saturated suction
at compressor
Outdoor ambient temperature
Temperature Pressure 55°F 65°F 75°F 85°F 95°F 105°F 115°F
(°F) (psig) MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
35 107 36.8 1.41 35.2 1.69 33.4 1.94 31.3 2.20 29.1 2.47 26.7 2.77 24.2 3.14
40 118 40.6 1.44 38.8 1.71 36.8 1.96 34.5 2.21 32.0 2.48 29.5 2.78 26.9 3.14
45 130 44.6 1.49 42.6 1.75 40.3 1.99 37.8 2.23 35.2 2.49 32.5 2.79 29.6 3.15
50 142 48.9 1.54 46.6 1.79 44.1 2.03 41.4 2.26 38.5 2.51 35.5 2.81 32.5 3.16
55 156 53.3 1.62 50.8 1.85 48.0 2.07 45.0 2.30 42.0 2.55 38.8 2.84 35.5 3.18
Condenser only performance data notes
• For outdoor unit (condenser) performance only. Data does not include the effects of air handler
power or heat.
• Performance based on 15°F subcooling and 15°F superheat at the outdoor unit base valves:
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
• Maximum recommended condensing temperature is 140°F.
Cooling performance data - 3 ton
Table 29: Cooling performance data - 3 ton - indoor coil: XAFB36DXXN1
IDCFM 950 1150 1350
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air
temperature
entering
outdoor unit
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
T.C. 32.5 36.0 36.0 39.7 42.9 34.4 37.3 37.3 41.0 44.3 36.4 38.6 38.5 42.2 45.7
S.C. 32.5 30.7 26.1 26.3 21.3 34.4 33.8 28.3 28.5 22.9 36.4 36.8 30.6 30.7 24.5
55
kW 2.02 2.02 2.02 2.00 1.99 2.08 2.09 2.09 2.08 2.07 2.15 2.16 2.16 2.15 2.14
T.C. 31.8 34.7 34.9 38.4 42.1 33.7 36.0 36.2 39.7 43.5 35.7 37.2 37.5 41.0 44.8
S.C. 31.8 29.9 25.4 25.7 20.9 33.7 33.0 27.8 28.1 22.7 35.7 36.1 30.3 30.4 24.4
65
kW 2.27 2.27 2.27 2.25 2.23 2.33 2.33 2.34 2.32 2.31 2.39 2.40 2.41 2.39 2.38
T.C. 31.0 33.3 33.8 37.2 41.3 33.0 34.6 35.1 38.5 42.7 35.1 35.9 36.4 39.9 44.0
S.C. 31.0 29.1 24.7 25.2 20.6 33.0 32.2 27.3 27.6 22.5 35.1 35.3 29.9 30.1 24.3
75
kW 2.52 2.51 2.52 2.50 2.48 2.58 2.58 2.59 2.57 2.55 2.64 2.64 2.66 2.64 2.62
63Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
