Table 33: Cooling performance data - 3.5 ton - indoor coil: XAFC42EXXN1
IDCFM 1200 1400 1600
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air
temperature
entering
outdoor unit
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
T.C. 31.1 31.1 30.0 33.6 35.9 32.3 32.1 30.8 34.5 36.3 33.6 33.1 31.6 35.4 36.7
S.C. 31.1 30.9 26.1 26.7 20.7 32.3 32.1 28.2 28.9 22.0 33.6 33.1 30.4 31.1 23.3
115
kW 4.36 4.38 4.44 4.37 4.30 4.43 4.44 4.50 4.44 4.39 4.49 4.49 4.57 4.51 4.47
Cooling performance data notes
• All capacities include indoor fan heat. kW values are for the system (outdoor + indoor).
Multipliers for determining the performance with other
indoor sections
Note: For dry bulb temperatures different than those listed (between 73°F to 87°F), sensible
capacity increases by 1060 Btu/h per 1000 CFM per degree above the listed temperature and
decreases by 1060 Btu/h per 1000 CFM per degree below the listed temperature.
Cool multiplier air handler - 3.5 ton
Table 34: Cool multiplier air handler - 3.5 ton
Air handler model Indoor coil model Total capacity Sensible capacity kW
— XAFC42E 1.00 1.00 1.00
— XAFC48F 1.02 1.01 1.00
— XAFD42E 1.02 1.03 1.00
— XAFD48F 1.02 1.01 1.00
— XAHC48F 1.02 1.01 1.00
— XAHD42E 1.01 0.98 0.99
— XAHD48F 1.02 1.01 1.00
— XAUC42E 1.00 1.00 1.00
— XAUC48F 1.02 1.01 1.00
JHVTC42FBCC2N1 — 1.00 0.93 0.92
JHVTD42FBCC2N1 — 1.00 0.92 0.92
JMET12CS2N1 XAFC48F 1.01 0.96 0.95
JMET12CS2N1 XAHC48F 1.01 0.96 0.95
JMET12CS2N1 XAUC48F 1.01 0.96 0.95
JMET16CS2N1 XAHC48F 1.05 1.07 0.97
JMET18DS2N1 XAFD42E 1.02 1.04 0.98
JMET18DS2N1 XAFD48F 1.02 1.04 0.98
JMET18DS2N1 XAHD48F 1.02 1.03 0.98
RFCC42FBCEMP2N1 — 1.01 0.97 0.95
Cool multiplier furnace - 3.5 ton
Table 35: Cool multiplier furnace - 3.5 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
RGF19080BE12MP13 XAFC42E 1.00 0.95 0.96
RGF19080BE12MP13 XAFC48F 1.00 0.94 0.96
RGF19080BE12MP13 XAHC42E 1.00 0.95 0.96
RGF19080BE12MP13 XAHC48F 1.00 0.94 0.96
RGF19080BE12MP13 XAUC42E 1.00 0.95 0.96
