Table 23: Cool multiplier furnace - 2 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
TM8Y060A12MP11 XAUA24B 0.99 0.91 0.93
TM8Y060A12MP11 XAUB30C 1.00 0.94 0.92
TM8Y080B12MP11 XAFB24B 1.00 0.93 0.94
TM8Y080B12MP11 XAFB30C 1.00 0.95 0.92
TM8Y080B12MP11 XAFC30C 1.00 0.95 0.92
TM8Y080B12MP11 XAHB24B 1.00 0.93 0.94
TM8Y080B12MP11 XAHB30C 1.00 0.94 0.92
TM8Y080B12MP11 XAHC30C 1.00 0.94 0.92
TM8Y080B12MP11 XAUB30C 1.00 0.95 0.92
TM8Y080C16MP11 XAFC30C 1.01 0.99 0.93
TM8Y080C16MP11 XAHC30C 1.01 0.99 0.93
TM8Y100C16MP11 XAFC30C 1.01 0.99 0.93
TM8Y100C16MP11 XAHC30C 1.01 0.99 0.93
TM8Y100C20MP11 XAFC30C 1.01 0.99 0.93
TM8Y100C20MP11 XAHC30C 1.01 0.99 0.93
TM8Y120C20MP11 XAFC30C 1.01 0.99 0.93
TM8Y120C20MP11 XAHC30C 1.01 0.99 0.93
TM9Y060B12MP11 XAFB24B 1.01 0.97 0.95
TM9Y060B12MP11 XAFB30C 1.01 0.98 0.95
TM9Y060B12MP11 XAFC30C 1.00 0.97 0.94
TM9Y060B12MP11 XAHB24B 1.01 0.95 0.97
TM9Y060B12MP11 XAHB30C 1.01 0.97 0.95
TM9Y060B12MP11 XAHC30C 1.00 0.97 0.94
TM9Y060B12MP11 XAUB30C 1.01 0.98 0.95
TM9Y080B12MP11 XAFB24B 1.01 0.97 0.95
TM9Y080B12MP11 XAFB30C 1.01 0.99 0.95
TM9Y080B12MP11 XAFC30C 1.00 0.98 0.94
TM9Y080B12MP11 XAHB24B 1.01 0.97 0.95
TM9Y080B12MP11 XAHB30C 1.01 0.99 0.95
TM9Y080B12MP11 XAHC30C 1.00 0.98 0.94
TM9Y080B12MP11 XAUB30C 1.01 0.99 0.95
TM9Y080C16MP11 XAFC30C 1.01 1.00 0.95
TM9Y080C16MP11 XAHC30C 1.01 1.00 0.95
TM9Y100C16MP11 XAFC30C 1.01 1.00 0.93
TM9Y100C16MP11 XAHC30C 1.01 0.99 0.95
TM9Y100C20MP11 XAHC30C 1.01 1.07 0.95
Performance data - 2.5 ton
See the following tables for performance and multiplier data for the RAC13430B21S unit.
Condenser only performance data - 2.5 ton
Table 24: Condenser only performance data - 2.5 ton
Saturated suction
at compressor
Outdoor ambient temperature
Temperature Pressure 55°F 65°F 75°F 85°F 95°F 105°F 115°F
(°F) (psig) MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
35 107 30.4 1.25 29.0 1.44 27.4 1.63 25.7 1.83 23.8 2.06 21.9 2.31 20.0 2.61
40 118 33.4 1.25 31.9 1.44 30.1 1.63 28.2 1.84 26.3 2.06 24.2 2.32 22.1 2.62
45 130 36.6 1.26 34.9 1.45 33.0 1.64 31.0 1.85 28.9 2.08 26.7 2.33 24.5 2.63
Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase56
